DIAL INDICATORS Schut for Precision
Mitutoyo Absolute Digimatic dial indicators ID‑C (continued)
Multifunctional dial indicators with special functions for various applications. Which includes
a version with min/max/P-P function, a version especially made for internal measurements, and a
version with built-in calculation function. The results, for example, inside and outside diameter,
groove width, bore diameter, and curve radius, are determined based on the spindle displacement x;
formula: Ax + B + Cx‑1. The coefficients A, B and C can be set and the calculations are processed and
displayed in real-time.
Measuring range: 0 - 50.8 mm. Storage for 3 preset values (for example size
Resolution: 0.0002 to 1 mm, switchable. setting ring).
ABS/INC switchable (except 543.310).
LCD 330° rotatable. Bridges for dial indicators with calculation
Digimatic data output. function.
On/off switch.
Reset/preset. Especially made for dial indicators with
Hold function. calculation function. Combined with these dial
Max. measuring speed: unlimited. indicators, these bridges can provide a multitude
Clamping stem: ø 8 mm. of solutions. For these bridges, see bridges
Adjustable tolerance limits. elsewhere in the catalog.
Protection: IP42.
Delivery with a manufacturer measuring report.
Power supply: 1 battery type CR2032.
Model with min/max/P‑P function (543.300)
Key lock function.
Model for internal measurements (543.310)
Spindle movement is displayed graphically
(determination of the reversal point).
Item No. Measuring Accuracy Measuring Price
range/mm mm force/N EUR
With min/max/P‑P function: 511.00 543.300
543.300 0 - 12.7 ± 0.003 ≤ 1.5 543.340
For internal measurements: 563.00 543.310
543.310 0 - 12.7 ± 0.003 ≤ 1.5
With calculation function: 629.00
543.340 0 - 12.7 ± 0.003 ≤ 1.5 707.00
543.590 0 - 25.4 ± 0.003 ≤ 1.8 848.00
543.595 0 - 50.8 ± 0.006 ≤ 2.3
Options: 0.50 C05.346.EN.20240625
495.157 Spare battery type CR2032 37.00
905.338 Digimatic signal cable, 1 m 44.00
905.409 Digimatic signal cable, 2 m 124.00
106.384 USB Input Tool Direct cable, 2 m 98.00
102.795 U-WAVE data cable 15.00
210.198 Retraction lever 34.30
211.301 Cable retraction device 15.00
101.040 Back plate with lug
