Schut Geometrical Metrology DIAL INDICATORS

Digital dial indicators with high resolution

Digital dial indicators with digital and digital-analog read-out and a high resolution of 0.0005 mm.

 Measuring range: 0 - 50.8 mm.  Dial diameter: 62 mm.
 Resolution: 0.0005.  Dial 270° rotatable.
 mm/inch conversion.  With determination of the reversal point.
 ABS/INC switchable.  Protection: IP54.
 On/off switch.  Delivery with USB-C and
 With data output.
 USB-C data output: for data transfer to a manufacturer measuring
report; excluding USB
PC (e.g. Excel, Word), operating system charger.
Windows and other.  Power supply:
 Mutifunctional functions: automatic switch- rechargeable battery.
off, adjustable tolerance limits, reversible
measuring direction, hold-function, min/max-
function.
 Reset/preset.
 Clamping stem: ø 8 mm.

Item No. Measuring Resolution Accuracy Measuring Price
range/mm mm mm force/N EUR

910.340 0 - 15 0.0005 ± 0.002 ≤1.5 310.00 910.340
911.184 0 - 25.4 0.0005 ± 0.002 ≤1.8 302.00 909.251
911.185 0 - 50.8 0.0005 ± 0.004 ≤2.3 341.00

Option: 75.00
910.457 * Bluetooth transmitter

* With USB-C connection.

Digital dial indicators

Digital dial indicators with digital and digital-analog read-out.

 Measuring range: 0 - 12.5 mm.  Dial diameter: 62 mm.
 Resolution: 0.002 or 0.0005 mm.  Dial 315° rotatable.
 mm/inch conversion.  With determination of the
 ABS/INC switchable.
 On/off switch. reversal point.
 Mutifunctional functions: automatic switch-  Delivery in a plastic case.
 Power supply:
off, adjustable tolerance limits, reversible
measuring direction. 1 battery
 Reset/preset. type CR2032.
 Clamping stem: ø 8 mm.

Item No. Measuring Resolution Accuracy Measuring Price
range/mm mm mm force/N EUR

909.250 0 - 12.5 0.002 ± 0.015 1.2 112.00
909.251 0 - 12.5 0.0005 ± 0.006 1.2 210.00

Option: 0.50 C05.342.EN.20240625
495.157 Spare battery type CR2032
