INTERNAL & EXTERNAL MEASURING INSTRUMENTS Schut for Precision

HELIOS-PREISSER universal gauge

Universal measuring instrument consisting of a steel tube with two mobile measuring arms. The
measuring direction is reversible, which enables measurements of internal and external dimensions.

 Measuring range: ø5 ø523/53
external measurements: 5 - 220 mm, 52
internal measurements: 15 - 230 mm. ø6
10
 Measuring range with optional 856.319/387 856.388
extensions: up to 2000 mm. ø5

 Clamping shaft: ø 8 mm.
 Reversible measuring direction.
 Large choice of measuring probes and inserts.
 Inserts also for internal and external screw

thread measurements available.
 Base instrument: excl. dial indicator,

measuring probes and inserts.
 Delivery in a wooden case.

Item No. Description Price EUR 41 30/50

856.721 Base instrument 2,099.00

Options: Measuring probe mounting blocks 289.00 ø6 ø111
856.732 (pair) for external dimensions 11 856.734/736
Measuring probe mounting blocks 289.00
856.735 (pair) for internal dimensions 856.389
Extension 100 mm 292.00
856.723 Extension 200 mm 310.00 ø5
856.722 Extension 400 mm 474.00
856.724 Ball inserts (pair) 130.00 Detailed 5
856.319 l = 23 mm information 5 13
Ball inserts (pair) 130.00
856.387 l = 53 mm available 6
Cylindrical inserts (pair) 130.00 856.725
856.388 Offset inserts (pair) 216.00 Illustrated:
856.389 Shoulder insert (pair) 351.00 base instrument, ­measuring ø5
856.725 for external dimensions arms, ball inserts, extension
Shoulder insert (pair) 351.00 and dial indicator. 5 13
856.733 for internal dimensions 5
Measuring insert discs (pair) 111.50 856.732/735
856.736 0 - 20 mm l = 30 mm 6
Measuring insert discs (pair) 111.50 856.733
856.734 20 - 40 mm l = 50 mm
Measuring arms (pair) 326.00 856.726
856.726 l = 35 mm
Measuring arms (pair) 348.00 856.731
856.727 l = 70 mm
Depth stop attachments 297.00 ø3,5
856.731 for measuring arms (pair) ø7,5
Adapters 5 mm 34.25 ø7,5
856.728 for inserts M2.5 (pair)
Measuring inserts flat (pair) 70.00 ø3,5
856.737 Measuring inserts spherical (pair) 70.00
856.738 C04.339.EN.20240625

856.713 1 Adapters new to old (pair) 89.00
856.717 2 Adapters old to new (pair) 89.00

1 For new model accessories on an old 856.380. 63 36
2 For old model accessories on a new 856.721. 856.737 856.738

ø5
