P. 212
DIAL INDICATORS Schut for Precision
Absolute digital dial indicators
Measuring range: 0 - 50.8 mm. Adjustable tolerance limits (except 910.004).
Resolution: 0.01 mm or 0.001 mm. Flat back.
mm/inch conversion. With additional back with lug
ABS/INC switchable.
LCD display 330° rotatable. (only 909.998, 910.001/004).
Digimatic data output. Protection: IP54.
On/off switch. Delivery with a manufacturer measuring report.
Reset/preset. Power supply: 1 battery type CR2032.
Ceramic stylus tip.
Max. measuring speed: unlimited.
Measuring force: ≤ 2 N.
Clamping stem: ø 8 mm.
Dial diameter: 60 mm.
Reversible measuring direction.
With determination of the reversal point (only
910.004).
USB interface: 909.998 910.004
– For data transfer to PC
Item No. Measuring Resolution Accuracy Price
(e.g. Excel, Word). range/mm mm mm EUR
– Operating system:
Windows and other.
– PC connection: USB.
– No software or driver to install.
– Foot switch (optional).
909.998 0 - 12.7 0.001 ± 0.004 149.00
909.999 0 - 25.4 0.001 ± 0.005 196.00
910.000 0 - 50.8 0.001 ± 0.006 271.00
910.001 0 - 12.7 0.01 ± 0.01 84.00
910.002 0 - 25.4 0.01 ± 0.01 107.00
910.003 0 - 50.8 0.01 ± 0.015 149.00
± 0.004 163.00
909.686 For internal measurements:
910.004 0 - 12.7 0.001
909.611 With Bluetooth: 0.001 ± 0.004 160.00
910.079 0 - 12.7 0.01 ± 0.01 100.00
910.082 0 - 12.7
909.687 Options: 0.50
910.039/038 495.157 Spare battery type CR2032 109.00
909.613 909.686 1,2 USB interface 18.50
909.687 Footswitch for USB interface 50.00
910.038 Wireless USB receiver 50.00
910.039 2 Wireless transmitter
909.611 Retraction lever 1.10
909.613 Cable retraction device (0.4 m) 14.50
(maximum travel 10 mm) 6.40
909.614 Retraction lever
909.614 C05.326.EN.20240625
(maximum travel 12.7 mm)
1 Standard configured for PC with English (US) keyboard.
Also available on request for alternative keyboards.
2 For instruments with a Digimatic data output.
