Schut Geometrical Metrology INTERNAL & EXTERNAL MEASURING INSTRUMENTS

Universal measuring instruments (continued)

Interchangeable inserts for type MA Interchangeable measuring disc for type MB
A measuring disc, which can be fitted by means
Item No. Description Price EUR
(2 needed) per piece of spacers and a support washer, is available for
measuring arms MB with internal thread M6.
856.351 Spherical disc insert 116.00 For measuring of shoulders at different levels,
856.372 Flat disc insert 174.00 locating flanges, etc.
856.352 Spherical needle 149.00
204.00 Measuring arms
ø 2 x 5 mm 192.00 MB
856.376 Spherical needle
856.364
ø 2 x 25 mm 856.359 - 856.363
856.353 Ball insert ø 3 mm 856.358

856.351: 856.352:
measuring measuring
of bores of narrow
grooves

856.353: measuring Item No. Description Price EUR
of internal gear teeth, (2 needed) per piece
V‑grooves, etc.
Available on request: inserts for thread 856.358 Measuring disc ø 15 x 4 mm 112.00
pitch diameters (metric: pitch 0.5 - 7.0; 856.359 Spacer 1 mm 36.80
BSW: 14 - 3.0 t.p.i.; UN: 32 - 3.0 t.p.i.). The 856.360 Spacer 2 mm 36.80
measuring anvils rotate to follow the helix 856.361 Spacer 3 mm 36.80
of the thread. 856.362 Spacer 6 mm 36.80
856.363 Spacer 10 mm 36.80
856.364 Support washer ø 30 x 3 mm 50.00

Example of Extensions and connecting elements
a complete
instrument with Item No. Description Price EUR
measuring
arms type MB, 856.354 Extension 300 mm 357.00
measuring discs 856.355 Extension 500 mm 583.00
and a dial indicator. 856.356 Connecting element for 332.00
© 2025, Schut Geometrische Meettechniek bv measuring element and extension
856.357 End cover for 54.00
extension
C04.231.EN.20250106
Before placing the extension the measuring direction
has to be determined with the adjusting screw.

207 Measuring instruments and systems 2023/2024
