Schut Geometrical Metrology DIAL INDICATORS

Mitutoyo Absolute Digimatic dial indicators ID‑C

Digital dial indicators with the absolute measuring system and a large display for easy reading of
the measuring values and the tolerance judgement. The tolerance values are shown graphically above
the current measurement on the display. The 330° rotatable display guarantees an ideal read-out in
any position.

 Measuring range: 0 - 50.8 mm.  Max. measuring speed: unlimited.
 Resolution: 0.01 or 0.0005/0.001/0.01 mm.  Clamping stem: ø 8 mm.
 Repeatability: 0.01 mm.  Tungsten carbide stylus tip.
 ABS/INC switchable.  Reversible measuring direction.
 Bidirectional data output.  Adjustable tolerance limits.
 LCD display 330° rotatable.  Protection: IP42.
 Digimatic S1 data output.  Conforms to factory standard.
 On/off switch.  Calibration date warning.
 Reset/preset.  Delivery with a manufacturer measuring report.
 Hold function.  Power supply: 1 battery type CR2032.
 Min/max/P‑P function.

543.715 543.705

543.725

Item No. Measuring Resolution Accuracy Measuring Price
range/mm mm mm force/N EUR

543.710 0 - 12.7 0.01 ± 0.02 ≤ 0.9 333.00
543.725 0 - 25.4 0.01 ± 0.02 ≤ 1.8 450.00
543.735 0 - 50.8 0.01 ± 0.04 ≤ 2.3 702.00
543.700 0 - 12.7 0.0005/0.001/0.01 ± 0.003 ≤ 1.5 446.00
543.720 0 - 25.4 0.0005/0.001/0.01 ± 0.003 ≤ 1.8 567.00
543.730 0 - 50.8 0.0005/0.001/0.01 ± 0.005 ≤ 2.3 848.00

With a reduced measuring force:
543.715 0 - 12.7 0.01 ± 0.02 ≤ 0.2 - 0.5 394.00
543.705 0 - 12.7 0.0005/0.001/0.01 ± 0.003 ≤ 0.4 - 0.7 540.00

Options: 0.50 C05.345.EN.20240625
495.157 Spare battery type CR2032 79.00
106.011 Digimatic S1 signal cable without data switch, 1 m 84.00
106.021 Digimatic S1 signal cable without data switch, 2 m 164.00
106.001 USB Input Tool Direct cable S1, 2 m 131.00
102.011 U-WAVE data cable 340.00
106.543 USB-ITPAK V3.0
