P. 219
Schut Geometrical Metrology DIAL INDICATORS
Mitutoyo Absolute Digimatic dial indicators ID‑B and ID‑N
Compact digital dial indicators with the Absolute measuring system and with protection degree
IP66. Flexible mounting because the display can also display upside-down.
Measuring range: 0 - 12.7 mm. Tungsten carbide stylus tip.
Resolution: 0.01 or 0.001 mm. Reversible measuring direction.
ABS/INC switchable. Adjustable tolerance limits.
Digimatic data output. Protection: IP66.
On/off switch. Conforms to factory standard.
Reset/preset. Power supply: 1 battery type V357.
Hold function.
Max. measuring speed: unlimited.
Measuring force: ≤ 2 N (0 - 5 mm),
≤ 2.5 N (0 - 12.7 mm).
Clamping stem: ø 8 mm.
Top view 543.580
543.580 543.575
(543.585) (543.570)
Data cables Digimatic, USB Input Tool Direct,
U-WAVE available on request.
Item No. Measuring Resolution Accuracy Price
range/mm mm mm EUR
312.00
543.580 0 - 5 0.01 ± 0.02 416.00
543.585 0 - 5 0.001 / 0.01 ± 0.003 / ± 0.01 278.00
543.570 0 - 12.7 0.01 ± 0.02 389.00
543.575 0 - 12.7 0.001 / 0.01 ± 0.003 / ± 0.01
0.90
Option: C05.318.EN.20240625
836.535 Spare battery type V357
© 2024, Schut Geometrische Meettechniek bv 219 Measuring instruments and systems 2023/2024
