Schut Geometrical Metrology DIAL INDICATORS

TESA Digico digital mini dial indicators 12/12‑HP

Designed to work in the toughest conditions, protected against spraying water, oil and coolants.
The diameter of the housing is only 44 mm. Patented, inductive measuring system. The Digico 12‑HP
dial indicators (*) are high-precision models.

 Measuring range: 0 - 12.5 mm. TESA Digico 12‑HP *
 Resolution: 0.01 mm or 0.001 / 0.01 mm.  Accuracy: ± 0.002 mm.
 Accuracy: ± 0.01 mm.  Repeatability: 0.002 mm.
 Repeatability: 0.005 mm.  With digital-analog display of the measured
 mm/inch conversion.
 ABS/INC switchable (except 12‑HP). value (± 0.025 to ± 1.25 mm).
 RS232C data output with external power supply.  Lock of automatic switch-off.
 Automatic switch-off.  Min/max/P‑P function.
 Preset (except 12‑HP) and reset.
 Max. measuring speed: 2 m/s.
 Measuring force: 0.5 ‑ 0.9 (± 0.15) N.
 Reversible measuring direction (except

12‑HP).
 Protection: IP65.
 Delivery with a manufacturer measuring

report (except the 0.01 mm models).
 Power supply: 1 battery type CR2032.

782.437

782.435

Item No. Measuring Resolution Price
range/mm mm EUR

Mechanics and electronics IP65 protected:
782.433 0 - 12.5 0.01 305.00
782.435 0 - 12.5 0.001 / 0.01 419.00
782.437 * 0 - 5 0.001 / 0.01 417.00

Option: 0.50 C05.212.EN.20250106
495.157 Battery type CR2032
