DIAL INDICATORS Schut for Precision
TESA Dialtronic Easy and Dialtronic digital dial indicators
Digital dial indicators with a measuring range up to 150 mm. The Dialtronic indicators have a
tolerance judgement by means of a red/green coloring LED. Data output possible by means of the
free to download TESA Data-Viewer software.
Measuring range: 0 - 150 mm. Only Dialtronic models:
Resolution: 0.01 or 0.001 mm. Tolerance judgement.
Repeatability: 0.002 mm. Function for dynamic measurements (min,
mm/inch conversion.
Bidirectional data transfer. max, max-min) and memory for maximum
On/off switch. and minimum values.
Reset/preset. Programmable button.
Hold function. Multiplication factor.
Reversible measuring direction. Key lock function.
Measuring force: 0.65 - 0.90 N, except IP67 Resolution: 0.01 mm or 0.001 mm,
switchable.
models: 0.7 - 1.4 N.
Max. measuring speed: 1.7 m/s.
Display 270° rotatable.
Delivery with a manufacturer measuring
report.
Power supply: 1 battery type CR2032.
783.677 783.680
783.689
Item No. Measuring Accuracy Resolution Protection Dial Price 783.690
ø/mm EUR
range/mm mm mm 541.00 783.691
628.00
TESA Dialtronic Easy: IP51 59.8 644.00
783.677 0 - 12.5 ± 0.01 0.01 IP51 59.8 779.00
783.678 0 - 12.5 ± 0.004 0.001 922.00
731.00
TESA Dialtronic: IP54 59.8 890.00
783.679 0 - 12.5 ± 0.01 0.01 IP54 59.8 1,025.00
783.680 0 - 12.5 ± 0.003 0.001 IP67 59.8 1,478.00
783.681 0 - 12.5 ± 0.003 0.001 IP54 59.8 1,859.00
783.682 0 - 25 ± 0.01 0.01 IP54 59.8 2,018.00
783.683 0 - 25 ± 0.004 0.001 IP67 59.8
783.684 0 - 25 ± 0.004 0.001 IP54 58 0.50
783.685 0 - 50 ± 0.005 0.001 IP54 58 93.00
783.686 0 - 100 ± 0.006 0.001 IP54 58 97.00
783.687 0 - 150 ± 0.01 0.001 104.00
199.00
TESA Dialtronic with Bluetooth: IP54 59.8 348.00
783.704 0 - 12.5 ± 0.003 0.001 IP54 59.8 304.00
783.705 0 - 25 ± 0.004 0.001
Options: Battery type CR2032 C05.344.EN.20250106
495.157 Back with lug
783.688 Retraction lever for Dialtronic, measuring range up to 12.5 mm
783.689 Retraction lever for Dialtronic, measuring range up to 25 mm
783.690 Inductive USB cable for Dialtronic, 3 m
783.691 Power USB cable for Dialtronic, 3 m
783.673 90 deg. power USB cable for Dialtronic, 3 m
783.674
