TESA Dialtronic Compact digital mini dial indicators
Designed to be used in tight spaces thanks to the small dial diameter of just 45 mm. Protected
against dust, spraying water, oil and coolants due to the IP54 and IP67 protection.
Measuring range: 0 - 12.5 mm. 783.672
Resolution: 0.01 mm or 0.001 mm.
Accuracy: ± 0.004 mm, except
783.670: ± 0.01 mm.
Repeatability: 0.002 mm.
mm/inch conversion.
USB data output with external power supply.
Bidirectional data transfer.
Automatic switch-off.
Reset/preset.
Max. measuring speed: 1.7 m/s.
Measuring force: 0.5 ‑ 0.9 (± 0.20) N except
783.672: 0.6 ‑ 1.3 (± 0.20) N.
Reversible measuring direction.
Protection: IP54 except 783.672: IP67.
Delivery with a manufacturer measuring
report.
Power supply: 1 battery type CR2032,
external power supply via a USB cable.
783.670 Item No. Measuring Resolution Price
783.673 range/mm mm EUR
783.230 + 783.670 0 - 12.5 0.01 453.00
783.670 783.671 0 - 12.5 0.001 644.00
783.672 + 781.727 783.672 0 - 12.5 0.001 684.00
Options:
495.157 Spare battery type CR2032 0.50
783.230 Retraction lever 124.00
781.727 Retraction lever 28.00 C05.340.EN.20240625
783.673 USB cable (3 m) 348.00
