DIGITAL LENGTH MEASURING SYSTEMS Schut for Precision

Magnescale DS805S/812S USB gauges

Accurate and robust probes with USB interface for easy connection to a PC. Simple PC software
for connecting the USB probe can be downloaded for free. Measured values can be displayed with the
software and stored in a CSV file.

 Measuring range: 5 or 12 mm.  Operating temperature: 0 to 50°C.
 Resolution: 0.5 µm (0.1 µm on request).  Clamping stem: ø 8 mm.
 Cable length: approx. 2.5 m.  Resistant to oil, dirt, shocks and vibrations.
 Reference point.  Also available up to 100 mm measuring

range.

Item No. Type Price EUR

346.090 DS805SLR5 583.00
346.089 DS805SR5 553.00
346.095 DS812SR5 570.00
346.096 DS812SLR5 599.00
346.097 DS812SVR5 626.00

Type designation
DS8 05/12 S –/F –/L R
 Measuring range in mm.
 With (F) or without (–) flange.
 Cable connection:

axial, with spring push (–),
radial, with vacuum retract (L), or
radial, with pneumatic push (V).

Magnescale MT30 USB adapter for DT probes

Using the MT30 adapter, a DT probe can easily be connected to the USB port of a PC. The
MT30-01 is suitable for DT512 probes. The MT30-05 is suitable for DT12 and DT32 probes. Simple
PC software for connecting the USB probe can be downloaded for free. Measured values can be
displayed with the software and stored in a CSV file.

Item No. Type Price EUR
346.418 MT30 - 01 250.00
346.419 MT30 - 05 215.00

Favourably priced set of a DT probe with
MT30 adapter:

Item No. Type Price EUR

346.416 DT12N and MT30 - 05 360.00
346.417 DT12P and MT30 - 05 398.00

Sets are also available with DT32 and DT512
probes on request.

DT12P C01.331.EN.20240625
