Schut Geometrical Metrology DIGITAL LENGTH MEASURING SYSTEMS
Cables and configuration Magnescale DK gauges
Item No. Type Length/m Price EUR
Adapter cables: 0.3 74.00 Configuration A/B phase LG20
346.145 CE29‑003 1 74.00 DK8**B reference point LH70/71
346.146 CE29‑01 3 89.00 DK830S LY71/72
346.147 CE29‑03 5 111.00 Cable unit
346.148 CE29‑05 10 147.00 DK10-205 CE29
346.149 CE29‑10
DS8xxS LT30
Item No. Type Length/m Price EUR
Extension cables: 1 79.00 MG20A-DK
346.741 CK‑T12 3 102.00
346.742 CK‑T13 5 125.00 MG80 RS232C/BCD
346.743 CK‑T14 10 181.00
346.744 CK‑T15 1 Ethernet
346.745 CE22‑01 1 3 66.00 Ethernet/IP
346.746 CE22‑03 1 5 81.00 Profinet
346.747 CE22‑05 1 10 101.00
346.748 CE22‑10 1 144.00 USB
1 Open end, TTL line driver RS422.
Magnescale DF805S/812S gauges + MF10 Digital Tolerance Indicator
The robust DF probes combine a high resolution with a compact body. The MF10 counter module
is suitable for the DF and DT probes. The module has a clear display and can also generate Go/NoGo
output.
Measuring range: 5 or 12 mm. Item No. Type Price EUR
Resolution: 0.1 µm. 346.540 DF805SR 761.00
Go/NoGo tolerance evaluation. 346.541 DF805SLR 800.00
346.542 DF805SFR 800.00
Configuration Cable unit MF10 NPN 346.543 DF805SFLR 837.00
DF805S/ CE34 PNP 346.544 DF812SR 786.00
DF812S 346.545 DF812SLR 827.00
346.546 DF812SFR 827.00
Type designation 346.547 DF812SFLR 862.00
DF8 05/12 S –/F –/L R Item No. Type Length/m Price EUR
Measuring range in mm.
With (F) or without (–) flange. Extension cables: 0.5 46.00
Cable connection: 346.548 CE34‑005 2 68.00
346.549 CE34‑02 5 90.00
axial, with spring push (–), 346.550 CE34‑05 10 124.00
radial, with vacuum retract (L). 346.551 CE34‑10 15 170.00
346.552 CE34‑15 20 204.00
Item No. Type/description Price EUR 346.553 CE34‑20
346.414 MF10-P1 NPN output 209.00 C01.330.EN.20241127
346.415 MF10-P2 PNP output 209.00
© 2024, Schut Geometrische Meettechniek bv 15 Measuring instruments and systems 2023/2024
