DIGITAL LENGTH MEASURING SYSTEMS                                                   Schut for Precision

Magnescale DT gauges

  These gauges are especially suitable for the built-in display LT10A (DT12/32) and LT11A (DT512).
Together they form an economically favourable and very compact measuring system. The gauges
DT512 are the same as the DT12 gauges, but have a resolution of 1 µm (in combination with the
detector MT12 this is 5 µm).

	 Measuring range: 12 mm or 32 mm.                 	 Dimensions l x w x t and weight (excl. cable unit):
	 Highest resolution: 	                              DT12/512N:	 116   x 35 x 12 mm,   75 g,
                                                      DT12/512P:	 116   x 35 x 12 mm,   80 g,
  DT12/32: 5 µm, DT512: 1 µm.                         DT32N/P:	 218   x 35 x 12 mm, 120 g,
	 Accuracy: 	                                        DT32NV/PV: 217.5 x 35 x 12 mm, 140 g.

  DT12/32: ± 5 µm, DT512: ± 3 µm.                   	 Protection DT12P/512P,
	 Measuring force at 20°C: 	                         DT32P/PV: IP64.

  DT12/512N:	upward:	 0.7 ± 0.5 N, 	                                     DT12P                             DT12N
  	 lateral:	 0.8 ± 0.5 N,
  	 downward:	0.9 ± 0.5 N, 	                        Item No. Type                  Resolution 	            Price
  DT12/512P:	≤ 1.7 N, 	                                                                µm                  EUR
  DT32N/NV: upward:	 1.1 ± 0.8 N,
  	 lateral:	 1.3 ± 0.8 N,
  	 downward: 1.5 ± 0.8 N,
  DT32P:	 ≤ 2.9 N,
  DT32PV:	 ≤ 9   N.
	 Spring push, except DT32NV/PV:
  pneumatic push.
	 Cable length: 2 m.

                                                    To LG20, LH70/71, LY71/72, LT20A:
                                                    346.871 MT12‑10 	 10                                   203.00
Item No. Type         Measuring 	 Price
                      range/mm EUR
                                                    To LT30/MG80:
344.855 DT12N      	    12                  275.00  346.852 MT13‑05 	                       5              217.00
344.856 DT12P      	    12                  322.00
346.495 DT32N      	    32                  484.00  A/B phase (TTL line driver RS422):
346.496 DT32P      	    32                  537.00  346.874 MT14‑01 	                       1              280.00
346.497 DT32NV     	    32                  604.00  346.875 MT14‑05 	                       5              217.00
346.498 DT32PV     	    32                  659.00
344.853 DT512N     	    12                  342.00  334.684 AC adapter for MT14                            22.70
344.854 DT512P     	    12                  405.00
                                                    To MF10:                                1              226.00
346.477 Adapter DZ51                         50.00  346.412 MT20‑01 	                       5              180.00
346.793 Adapter SZ70‑1                      128.00  346.413 MT20‑05
346.145 CE29‑003
                                             77.00  Configuration LT10A  Detector  LT20A                     LG20
                                                       DT12/32             MT12                            LH70/71
344.426 * Pneumatic retraction 	            235.00                                                         LY71/72
           device DZ176                                                  Detector
                                                                           MT13    Adapter     Adapter
                                                                                     DZ51       SZ70-1

*	Only for the DT12 and DT512 gauges.                                                     Cable unit
                                                                                               CE29
                                                    DT512
                                                                                   LT30

Item No. Type      Length/m Price EUR                            LT11A
Extension cables:
346.136 CE08‑1                                                                     MG80
346.137 CE08‑3
346.138 CE08‑5     	1                        57.00                       Detector  Differential A/B phase       MF10-P1
346.139 CE08‑10    	3                        80.00                         MT14            line driver                    MG51
346.140 CE08‑15    	5                       104.00
                   	 10                     162.00                       Detector                          MF10-P2              C01.322.EN.20250321
                   	 15                     220.00                         MT20
                                                    DT12/32/512                    USB         MF10-CM
                                                                         Detector
                                                                           MT30

© 2025, Schut Geometrische Meettechniek bv          18 Measuring instruments and systems 2025/2026
