DIGITAL LENGTH MEASURING SYSTEMS Schut for Precision

Magnescale DK10/25/50/100/155/205 gauges

The Magnescale DK gauges are developed using the MR (magneto­resistance) sensor principle and
have direct A/B phase output. The gauges either have a spring push and a built‑in reference point at
1 mm (DK10‑100) or no spring push, and with a built‑in reference point at 5 mm (DK155/205) from
the idle point of the spindle.

 Measuring range: up to 205 mm.  DK10‑100: carbide ball tip ø 2.5 mm.
 Resolution: 0.5 µm. DK155/205: flat magnet ø 22 mm (10 N) with
 Max. measuring speed: 250 m/min. in the center a ball ø 4 mm.
 Clamping stem: ø 20 mm (DK155/205: ø 32 mm).
 Output: A/B phase and reference point Z  Reference point.
 Operating temperature: 0 to 50°C.
(TTL line driver RS422).  Protection: IP50 or IP64.
 Cable length: 2.5 m  Resistant to shocks and vibrations.
 Power supply: 5± 5% Vdc, 1 W.
(with extension cable: max. 22 m).

For measuring stands
with clamping shaft
ø 20 mm, ø 25 mm or
ø 32 mm see measuring
stands elsewhere in this
catalog.

Type designation

DK 10/25/50/100/155/205 N/P –/L R5

 Measuring range in mm. Item No. Type Accuracy Measuring Dimensions Price
 Protection: p‑p/µm force 1/N mm EUR

IP50 and with a reduced 346.853 DK10NR5 2 2 0.3 / 0.6 / 0.8 ø 20 x 122 836.00
measuring force (N), or 346.854 DK10PR5 2 ≤ 4.9 ø 20 x 122 836.00
IP64 (P). 346.855 DK10PLR5 2 ≤ 4.9 ø 20 x 102.5 836.00
 Cable connection: 346.857 DK25NR5 2 2 0.4 / 0.7 / 1 ø 20 x 179.5 911.00
axial (–) or 346.856 DK25NLR5 2 2 0.4 / 0.7 / 1 ø 20 x 160 911.00
radial (L). 346.858 DK25PR5 2 ≤ 4.9 ø 20 x 179.5 911.00
346.859 DK25PLR5 2 ≤ 4.9 ø 20 x 160 911.00
346.860 DK50NR5 2 2 – / 0.9 / 1.3 ø 20 x 286 1,005.00
346.861 DK50PR5 2 2 6.2 ø 20 x 286 1,005.00
346.862 DK100NR5 2 4 – / 1.8 / 2.7 ø 25 x 443.51,409.00
346.863 DK100PR5 2 4 9.3 ø 25 x 443.51,409.00
346.864 DK155PR5 5 2.7 ø 32 x 571 1,600.00
346.865 DK205PR5 6 2.7 ø 32 x 721 1,775.00

1 In case of reduced measuring force (N types): measuring force upward, lateral and C01.320.EN.20241127
downward, respectively.
2 Also available as models with USB interface.
