Schut Geometrical Metrology                            DIGITAL LENGTH MEASURING SYSTEMS

Cables and configuration Magnescale DK gauges

Item No. Type         Length/m Price EUR

Adapter cables:                0.3           77.00     Configuration     A/B phase               LG20
346.145 CE29‑003 	             1             77.00           DK8**B   reference point          LH70/71
346.146 CE29‑01 	              3             92.00          DK830S                             LY71/72
346.147 CE29‑03 	              5            115.00                      Cable unit
346.148 CE29‑05 	             10            152.00         DK10-205         CE29
346.149 CE29‑10
                                                            DS8xxS                LT30
Adapter:           	                        98.00
346.005 DZ262

Extension cables:  	           1             82.00                    Adapter           LT20A
346.741 CK‑T12     	           3            105.00                     DZ262
346.742 CK‑T13     	           5            129.00
346.743 CK‑T14     	          10            187.00                         MG80
346.744 CK‑T15     	           1
346.745 CE22‑01 1  	           3             68.00                                      Ethernet
346.746 CE22‑03 1  	           5             84.00                                      Ethernet/IP
346.747 CE22‑05 1  	          10            104.00                                      Profinet
346.748 CE22‑10 1                           149.00
                                                                                        USB

1	Open end, TTL line driver RS422.

Magnescale DF805S/812S gauges + MF10 Digital Tolerance Indicator

  The robust DF probes combine a high resolution with a compact body. The MF10 counter module
is suitable for the DF and DT probes. The module has a clear display and can also generate Go/NoGo
output.

	 Measuring range: 5 or 12 mm.                        Item No. Type                    Price EUR
	 Resolution: 0.1 µm.                                 346.540 DF805SR                      787.00
	 Go/NoGo tolerance evaluation.                       346.541 DF805SLR                     827.00
                                                       346.542 DF805SFR                     827.00
Configuration     Cable unit      MF10      NPN        346.543 DF805SFLR                    865.00
     DF805S/          CE34                  PNP        346.544 DF812SR                      813.00
     DF812S                                            346.545 DF812SLR                     855.00
                                                       346.546 DF812SFR                     855.00
Type designation                                       346.547 DF812SFLR                    891.00

DF8 05/12 S –/F –/L R                               Item No. Type       Length/m Price EUR
 Measuring range in mm.
 With (F) or without (–) flange.                      Extension cables:    0.5                 48.00
 Cable connection: 	                                  346.548 CE34‑005 	   2                   70.00
                                                       346.549 CE34‑02 	    5                   93.00
   axial, with spring push (–), 	                      346.550 CE34‑05 	   10                  128.00
   radial, with vacuum retract (L).                    346.551 CE34‑10 	   15                  176.00
                                                       346.552 CE34‑15 	   20                  211.00
Item No. Type/description                   Price EUR  346.553 CE34‑20

346.414 MF10-P1 NPN output                  216.00                                                      C01.330.EN.20250321
346.415 MF10-P2 PNP output                  216.00
