Schut Geometrical Metrology VISES

Modular precision vises 909.706

Hardened precision vises for fixation for various machine operations.

 With or without 90° rotatable base. 909.702
 Accuracy (parallelism, flatness and

squareness):
≤ 100 mm jaw opening = 0.005 mm,
> 100 mm jaw opening = 0.005 mm per 100 mm.
 Also available:
– intermediate sizes with other jaw depths
and jaw openings,
– larger models with jaw width 200 or
300 mm and jaw opening up to 600 mm.

Jaw opening Jaw width Jaw depth Length Without rotatable base With rotatable base
mm mm mm mm Item No. Price EUR Item No. Price EUR

100 100 30 270 909.702 533.00 909.706 829.00
150 125 40 345 909.703 711.00 909.707 1,075.00
200 150 50 420 909.704 840.00 909.708 1,203.00
400 175 60 655 909.705 1,289.00 909.709 1,770.00

Long modular vises

Long hardened vises for fixation for various machine operations.
 Single or two-sided model.
 Also available:

– intermediate sizes with other jaw depths
and jaw openings,
– larger models with jaw width 200 mm
and jaw opening up to 700 mm (single)
or 250 mm (two-sided).

909.714

909.710

Jaw width Jaw depth Length Single Two-sided
mm mm mm Item No. Jaw opening/mm Price EUR Item No. Jaw opening/mm Price EUR

100 30 460 909.710 290 932.00 909.714 90 988.00 C07.310.EN.20240626
125 40 520 909.711 320 997.00 909.715 100 1,115.00
150 50 580 909.712 360 1,359.00 –
150 50 680 – – 909.716 – 1,812.00
175 60 866 909.713 600 2,180.00 909.717 160 2,470.00
220
