Schut Geometrical Metrology VISES
Mini indexable collets Mounting by means of two M6 threaded
bores on the bottom-side.
Clamping range: 0.4 - 6 mm.
Per approx. 45 degrees indexable. Item No. Clamping range Dimensions Price
Aluminum, blasted. mm l x w x h/mm EUR
856.091 856.090 856.090 0.4 - 3.5 26 x 21 x 34 133.00
856.091 1.2 - 6 26 x 26 x 39 133.00
Stand for mini precision vises
Stand for use with mini precision vices in combination with base plates. The base plates can also be
used with other stands. For these stands see dial indicator stands elsewhere in the catalog.
Item No. Description Price EUR 856.087 670.057 +
856.087
670.057 Stand for 856.081 and 856.082 26.00
27.70
Base plates: 31.20
856.087 For 856.081
856.088 For 856.082
856.089 For 856.083
XY table for mini precision vises
XY table for accurate positioning underneath a microscope, for example.
Dimensions: 50 x 50 x 27 mm.
Range: 10 x 10 mm.
Graduation micrometers: 0.01 mm.
Item No. Description Price EUR 856.176 +
856.177 +
856.176 XY table 952.00 856.081
856.177 Adapter for mini precision vise 856.081 79.00
856.178 Adapter for mini precision vise 856.082 100.00 856.177
Mini V-block Mini magnetic V-blocks
Dimensions: 25 x 20 x 20 mm. V‑groove: 120°.
Hardened stainless steel construction. Hardened and ground steel.
Delivery incl. aluminum clamp.
Item No. Description Price EUR Item No. 856.173 Price EUR C07.319.EN.20240626
856.179 127.00 856.173 162.00
Mini V-block 856.174
for shafts ø 2.5 - 18 mm 856.174 182.00
Description
Mini V-block 20 x 20 x 17.5 mm
for shafts ø 2.0 - 25 mm
Mini V-block 30 x 30 x 25 mm
for shafts ø 4.0 - 35 mm
