Schut Geometrical Metrology V-BLOCKS / INDUCTION BLOCKS
Granite V‑blocks in pairs
V‑groove: 90°. 402.156
Material: granite.
Processed in matched pairs. h
Delivery in an aluminum carrying w
case with a manufacturer measuring
report.
l
Dimensions Capacity Weight Item No. Accuracy Price Item No. Accuracy Price
l x w x h/mm ø/mm kg 1 µm 2 EUR µm 2 EUR
63 x 63 x 63 10 - 50 1.4 Class 1: Class 0:
100 x 100 x 100 15 - 75 5.6 402.155 ± 6 264.00 402.159 ± 3 286.00
100 x 160 x 160 25 - 125 14.2 402.156 ± 8 305.00 402.160 ± 4 330.00
160 x 250 x 250 60 - 200 55.2 402.157 ± 8 480.00 402.161 ± 4 522.00
402.158 ± 10 758.00 402.162 ± 5 830.00
1 Weight per pair.
2 Parallelism between measuring faces and base.
Magnetic induction blocks in pairs
These magnetic induction blocks are not magnetized themselves. They are placed on a magnetic
chuck to induce, to hold objects as for example round bars.
Material: steel and aluminum alloy.
Ground in matched pairs.
V-blocks (909.378)
Capacity: ø 7 - 50 mm.
V‑groove: 90°.
909.377
Item No. Dimensions Weight Price 909.378
l x w x h/mm kg EUR
1.18 54.00
909.377 100 x 50 x 25 1.13 60.00
909.378 50 x 60 x 48
Magnetic holders
Angles 45°, 90° and 135°.
909.342
Item No. Dimensions Thickness Holding Price
h x w/mm mm power/kg EUR
909.342 80 x 120 14 2.5 13.50 909.332 C07.205.EN.20240626
909.332 100 x 155 17 8 13.90 Measuring instruments and systems 2023/2024
