P. 304
VISES Schut for Precision
Precision vises
Hardened precision vises for accurate measurements and machine operations.
Accuracy (parallelism, flatness and Precision and universal sine vises
squareness): Stable and accurate to fix in each angle
≤ 100 mm jaw opening = 0.005 mm,
> 100 mm jaw opening = 0.005 mm per 100 mm. position (0 to 45°).
Universal precision vise
With horizontally and vertically ground prism With 360° rotatable base.
in the moveable jaw. Accurate degree scale.
Stable and accurate to fix in each angle
position (0 to 45°).
909.734
909.739 909.746
909.749
Item No. Jaw opening Jaw width Jaw depth Length Price 909.752
mm mm mm mm EUR Measuring instruments and systems 2023/2024
Precision vises: 50 25 150 80.00
909.733 60 75 35 200 112.00
909.734 80 100 45 250 215.00
909.735 120 125 50 300 360.00
909.736 155
909.737 25 25 10 65 44.00
909.738 65 50 25 140 64.00
909.739 100 75 35 190 80.00
909.740 120 100 45 240 169.00
909.741 155 125 50 280 246.00
Precision sine vises with swivelling front axis: 140 117.00
909.742 60 50 25 190 149.00
909.743 100 75 35 250 332.00
909.744 120 100 45
Precision sine vises with swivelling rear axis: 140 126.00
909.745 60 50 25 190 158.00
909.746 100 75 35 250 268.00
909.747 120 100 45
Universal sine vises: 140 215.00 C07.309.EN.20250106
909.748 60 50 25 200 308.00
909.749 90 75 35 250 512.00
909.750 120 100 45 300 674.00
909.751 155 125 50
Universal precision vise: – 946.00
909.752 80 70 30
© 2025, Schut Geometrische Meettechniek bv 304
