VISES Schut for Precision

Mini precision clamping tools

Miniature clamping tools for clamping of small products. Very well suited for measuring for
example with roughness testers, microscopes or measuring machines.

Mini precision vises Clamp jaw sets
Sets consisting of 1 pair plastic jaws, 1 pair with
 Accuracy (parallelism, flatness and stepped jaws and 1 jaw with a stopper in the
squareness): 0.02 mm. horizontal prism.

 856.081: brass, matt chrome-plated; 856.081
856.082 and 856.083: aluminum, matt
anodized.

 Standard supplied with 2 pairs of jaws
(hardened stainless steel and plastic): 1 side
with a ground horizontal and vertical prism
and 1 flat side.

 856.081 and 856.082: on the bottom-side
provided with 2 x M4 threaded bores with
center distances 42 and 62.5 mm;
856.083: on the bottom-side provided with
2 x M6 threaded bores with center distance
approx. 83 mm.

Item No. Jaw opening Jaw width Jaw depth Length Weight Price
mm mm mm mm kg EUR
856.081
856.082 14 15 8 50 0.075 104.00
856.083 23 25 15 75 0.16 139.00
32 35 21 100 0.4 196.00

Options Price stopper
EUR 856.084
Item No. Description
42.00
Clamp jaw sets: 57.00
856.084 For 856.081 85.00
856.085 For 856.082
856.086 For 856.083

Mini precision vises in a set

Mini precision vises in a set, consists of 856.081, 856.082 and 856.083 with matching clamp jaws.
 Delivery in a plastic carrying case.

Item No. Description Price EUR C07.318.EN.20250106
856.175 Mini precision vises in a set 654.00
