P. 307
Schut Geometrical Metrology PARALLEL BLOCKS / ANGLE BLOCKS
Granite square blocks with V‑nut and tapped holes
Multifunctional granite blocks for e.g. flatness and squareness measurements, with V‑nut and several
tapped holes. Hold workpieces on several faces.
Accuracy measuring faces: Equilateral cubic.
flatness conforms to DIN 876/0, Delivery with a manufacturer’s
squareness conforms to DIN 875/1.
certificate.
Screw thread of tapping holes:
402.170: M6, 402.171/172: M8.
Item No. Dimensions Flatness Squareness Weight Price
mm µm µm kg EUR
402.170 160 x 160 x 160 4 8 9.6 502.00
402.171 200 x 200 x 200 5 9 17 777.00
402.172 1 250 x 250 x 250 5 10 34 1,133.00
402.170
1 Delivery ex Groningen, Netherlands.
Four-sided cast iron parallel blocks in pairs
Hollow but yet stable cast iron parallel blocks because of the internal
bridge construction.
Class 3: Parallelism: 64 µm. Smooth planed. 403.622
Class 1: Parallelism: 16 µm. Hand scraped.
Class 0: Parallelism: 8 µm. Fine scraped.
Flatness conforms to DIN 876.
Squareness conforms to DIN 875.
Plan parallel and square matched in pairs.
Dimensions Weight Class 3 Class 1 Class 0
l x w x h/mm p. pair/kg Item No. Price EUR Item No. Price EUR Item No. Price EUR
150 x 150 x 100 18 403.628 500.00 403.624 796.00 403.620 942.00
200 x 150 x 100 28 403.629 1 699.00 403.625 1 1,042.00 403.621 1 1,300.00
300 x 225 x 150 60 403.630 1 1,073.00 403.626 1 1,812.00 403.622 1 2,150.00
400 x 300 x 200 140 403.631 1 2,110.00 403.627 1 3,530.00 403.623 1 4,160.00
1 Delivery ex Groningen, Netherlands.
Cast iron angle blocks with several clamping possibilities
Cast iron angle block, with four clamping faces with several slots
and taps, for aligning and clamping of tools and products. The four
faces are planparallel and square matched.
Slot width: 18 mm (403.607: 20 mm).
Item No. Dimensions Parallelism Squareness Weight Price
l x w x h/mm µm µm kg EUR
403.605 250 x 150 x 100 50 35 13 286.00 403.606 C07.271.EN.20250106
403.606 300 x 200 x 150 52 40 23 529.00
403.607 1 400 x 250 x 200 56 46 55 854.00
1 Delivery ex Groningen, Netherlands.
© 2025, Schut Geometrische Meettechniek bv 307 Measuring instruments and systems 2023/2024
