Schut Geometrical Metrology CLAMPING TABLES / ANGLE PLATES

Cast iron clamping tables with several clamping possibilities

These cast iron clamping tables offer many
possibilities for aligning and clamping products
for mechanical processing. The six faces are
parallel and square milled. Four of these faces
are equipped with several clamping slots and the
top face with T‑slots.
 Flatness according DIN 876/3.
 T‑slots according DIN 650.

403.613

Delivery ex Groningen, Netherlands

Item No. Dimensions Weight Nom. value Slot width Price
l x w x h/mm kg T‑slots/mm mm EUR

403.610 250 x 180 x 150 25 14 16 584.00
403.611 300 x 220 x 200 37 14 18 822.00
403.612 350 x 280 x 250 70 22 22 1,171.00
403.613 400 x 350 x 300 115 22 22 1,594.00
403.614 500 x 450 x 400 180 22 22 2,160.00
403.615 800 x 700 x 600 670 28 30 4,140.00

Cast iron angle plates with several clamping slots

These cast iron angle plates have several clamping slots both in the base and the clamping face,
which make them suitable for all kind of fixtures.

 Flatness according DIN 876. Item No. Dimensions Weight Flatness Slot width Price
 Squareness according DIN 875. l x w x h/mm kg and square- mm EUR
 Strengthened outsides. ness/µm
 Slots in base and clamping face.
Class 3, DIN 876/3, DIN 875/2:
403.292 150 x 75 x 100 4 30 12 105.00
403.293 200 x 100 x 150 8 30 14 155.00
403.294 275 x 150 x 200 20 40 17 292.00
403.295 300 x 150 x 250 24 45 19 340.00
403.296 1 400 x 225 x 300 45 50 23 558.00
403.297 1 500 x 300 x 400 85 60 23 927.00

Class 1, DIN 876/2, DIN 875/1: 12 150.00
403.286 150 x 75 x 100 4 15 14 242.00
403.287 200 x 100 x 150 8 15 17 407.00
403.288 275 x 150 x 200 20 20 19 506.00
403.289 300 x 150 x 250 24 22 23 859.00
403.290 1 400 x 225 x 300 45 25 23 1,402.00
403.291 1 500 x 300 x 400 85 30

403.283 Class 0, DIN 876/1, DIN 875/0: 7 12 201.00 C07.272.EN.20250321
403.280 150 x 75 x 100 4 7 14 299.00
403.281 200 x 100 x 150 8 9 17 487.00
403.282 275 x 150 x 200 20 11 19 716.00
403.283 300 x 150 x 250 24 12 23 1,076.00
403.284 1 400 x 225 x 300 45 15 23 1,776.00
403.285 1 500 x 300 x 400 85

1 Delivery ex Groningen, Netherlands.
