PROBES Schut for Precision

TESA analog probes (continued)

Type IEC Measuring Repeatability Maximum Max. Cable Probe
60529 inaccuracy/µm travel/mm exit movement
GT21 force/N µm
GT21HP IP65 0.2 + 3L3 spring, extend
GT22 IP64 0.63 0.01 0.07 + 0.4L 4.3 axial spring, extend
GT22HP IP65 0.63 0.01 0.2 + 3L3 4.3 axial vacuum, retract
GT61 IP64 0.63 0.01 0.07 + 0.4L 4.3 square vacuum, retract
GT62 IP65 0.63 0.01 1 + 4L 4.3 square spring, extend
612-A 1 IP65 0.9 0.05 1 + 4L 10.3 axial vacuum, retract
GT622 IP50 0.9 0.05 1 + 4L 10.3 square
GT41 IP65 1.0 0.05 1 + 4L 10.3 axial air pressure
GT42 IP65 2.0 0.05 0.2 + 5L2 10.3 square 1.1 bar, extend
GT43 IP65 0.63 0.01 0.2 + 5L2 0.7 axial spring, extend
GT44 IP65 0.63 0.01 0.2 + 5L2 0.7 square vacuum, retract
GT31 IP65 0.4 0.1 0.2 + 5L2 2.1 axial spring, extend
FMS100 IP40 0.4 0.1 0.2 + 50L2 2.1 square vacuum, retract
FMS102 IP50 0.1 0.1 0.2 + 3L3 0.7 square
FMS130 IP50 2.0 0.5 0.2 + 3L3 5.8 parallel –
FMS132 IP50 2.0 0.5 0.2 + 3L3 5.8 square air pressure
1 No bellow. IP50 2.0 0.5 0.2 + 3L3 5.8 parallel air pressure
2.0 0.5 5.8 square air pressure
air pressure

Mitutoyo digital gauges

The LG100 is a gauge measuring system designed by Mitutoyo to be incorporated into assembly
lines and inspection equipment. With the EH-counter or the EJ-counter modules, measurements can
be read-out and saved. By combining multiple EJ-counters on a DIN-rail, they can be read-out at the
same time with a maximum of 16 gauges. With the EJ-counters it is not only possible to have a USB
output, but also an output to Profinet, Ethernet, or CC-link. Through these outputs, the gauges can be
connected to a PLC-system. To process, and apply SPC to this data, optional software is available.
Gauges with a measuring range up until 50 mm are available with which a resolution of 0.1 μm and a
high accuracy are possible.

System configuration

EJ-series RS-232C/USB
USB

Industrial IF/IO
A/B phase
RS232

LG100-serie EH-counter

Detailed C05.348.EN.20250106
information

available
