PROBES Schut for Precision

TESA analog and digital probes

 Measuring range: ± 1.5, ± 2 or ± 5 mm.
 Protection: IP65.
 Other models, ranges and voltages available

on request.
 Also available wireless probes or as a model

with detachable cable.

TESA analog DC probes
Probes that produce a linear voltage

proportional to displacement that can be
connected to AD converters in a PC or to PLCs
and X-t plotters.

The probe consists of two parts that are
connected by a cable (2 m):
a. a conventional analog probe (diameter 8 mm),
b. the electronics module that converts the
signal to DC.

 Accuracy: from Item No. Type Measuring Price
(0.2 + 3.5 L2) µm (L in mm). range/mm EUR
Analog DC probes:
 Signal output: 782.977/978: ± 2 Vdc, 782.977 GTL21DC ± 2 884.00
782.979/980: ± 5 Vdc. 782.978 GTL22DC ± 2 900.00
782.979 GT61DC ± 5 1,046.00
 Power supply: ± 15 Vdc. 782.980 GT62DC ± 5 1,070.00
TESA digital USB probes Digital USB probes:
783.097 GTL21 USB ± 2 588.00
USB probes are easy to connect, using 783.098 GTL22 USB ± 2 625.00
plug & play and without using interface boards. 783.226 GTL222 USB ± 1.5 742.00
High accuracy guaranteed within the complete 783.099 GT61 USB ± 5 757.00
measuring range. 783.100 GT62 USB ± 5 773.00
 Compatible with software Data-Direct,

Stat-Express and Data-Viewer.
 Simple link with for example Excel files.

Option: 26.00
780.802 * Air tube connector, M4 thread

for tube ø 4.7 / ø 2 mm

780.802 * Also other models available.

Type Protection Measuring Repeatability Accuracy Max. Cable Probe
force/N µm µm (L in mm) travel/mm exit movement
GTL21DC
GTL22DC IP65 0.63 0.1 0.2 + 3.5 L2 4.3 axial spring, extend C05.322.EN.20240625
GT61DC IP65 0.63 0.1 0.2 + 3.5 L2 4.3 square vacuum, retract
GT62DC IP65 0.9 0.1 1 + 4 L 10.3 axial spring, extend
GTL21 USB IP65 0.9 0.1 1 + 4 L 10.3 square vacuum, retract
GTL22 USB IP65 0.63 0.1 0.4 + 2.4 L2 4.3 axial spring, extend
GTL222 USB IP65 0.63 0.1 0.4 + 2.4 L2 4.3 square vacuum, retract
GT61 USB IP65 1.2 0.1 0.4 + 2.4 L2 3.1 square
GT62 USB IP65 0.9 0.24 1 + 4 L 10.3 axial air pressure
IP65 0.9 0.24 1 + 4 L 10.3 square spring, extend
vacuum, retract
