Schut Geometrical Metrology PROBES
Analog probes
Half-bridge probes.
Measuring range: ± 0.25 to ± 10 mm.
Repeatability: < 0.15 µm.
Non-linearity: < 0.3%.
All non-pneumatic probes with cable guide
have a cable exit square to probe body.
PR10 91 27
PR2 47
PR3 15
67.5
PR1 16
22.5 8 26
4
PR05
Feather Touch probes
Probes with a very small measuring force to measure sensitive materials like electronic components
and thin-walled glass products.
Item No. Type Measuring Max. travel Measuring Total length Price
range/mm mm force/N mm EUR
Feather Touch probes with a small measuring force and tungsten carbide probe tip:
360.964 PRFC2P ± 1 3 0.18 / 1.10 1 75.6
360.965 PRFC5P ± 2.5 6 0.18 / 1.10 1 99.6
360.966 PRFC10P ± 5 11 0.18 / 1.10 1 130.1
360.962 PRFC5S ± 2.5 6 0.30 96.3
360.963 PRFC10S ± 5 11 0.30 118.3
Option:
360.967 Nylon probe tip
Probes with regular measuring force 3:
360.916 PR05 ± 0.25 0.6 0.70 26
360.917 PR1 ± 0.5 1.5 0.70 30.5
360.911 PR2 ± 1 2.5 0.70 62
360.912 PR2P ± 1 3.5 0.80 2 67
360.926 PR101P ± 1 11 0.70 2 117.5
360.910 PR10 ± 5 11 0.70 83.5
360.909 PR10P ± 5 11 0.70 2 87.5
360.905 PR20 ± 10 21 0.70 96.5
360.904 PR20P ± 10 21 0.70 2 118
Measuring range, measuring force and extended probe length defined at electrical zero.
P = Pneumatic, probe is operated by air pressure.
1 Air pressure 0.3 bar (nominal) / Air pressure 1.0 bar (nominal). C05.204.EN.20250106
2 Air pressure 0.4 bar (nominal).
3 Protection: IP65.
