MF MEASURING FIXTURE SYSTEM Schut for Precision

MF measuring fixture system MF’s high quality and low price make an
ideal addition to existing measuring systems and
MF is a universal construction system based can be applied in production plants.
on components to quickly and easy build custom
measuring fixtures. The universal properties of MF result in a
highly flexible construction system. The use
The system has been developed by Schut Geo­ of internationally applied units of fit for e.g.
metrical Metrology. The parts of MF are made dial indicators and electronic probes make the
from high quality steel and colored, anodized system’s components widely applicable. With
aluminum. just some base elements it is very easy to create
some individual measuring points on e.g. pro­
The system consists of, among other things, duction machines.
base plates, parallel spring elements, mounting
bars, probe holders and probes. A stable product Clamping bus
positioning is required for accurate measure­ (VKE)
ments and because of the system’s sophisticated
composition, it is possible to generate a com­
plete measuring system with only a few parts.
Ideal for repeating measurements.

The components of MF are based on both
horizontal support or vertical clamping. The
wide range and shapes of probes make the
system suitable for e.g. lathed parts but also
for (more complicated) milling parts. For these
various applications some complete sets are
available, as a starter-set or for specific appli­
ca­tions. Besides this, the variety of individual
components and the ease of use enable almost
endless possibilities of applying and in­cor­
po­rating MF in other measuring fixtures that
may be custom build or composed of other
construction systems.

All individual components are available
separately, increasing flexibility of use. Schut
Geometrical Metrology has incorporated MF
many times in custom built measuring systems
(see elsewhere in this catalogue).

Parallel spring element Download the
(PE) brochure from

Mounting bar Schut.com
(MS01)
Probe Holder ø 10 mm
(AF04) (SH02)

Length measuring element C22.201.EN.20250106
with stroke limit
(LEA)

Holder ø 8 mm
(AH04)
