DIAL INDICATOR STANDS Schut for Precision

Dial indicator stands 908.953/959 908.960

 Clamping shaft ø 8 mm for dial indicators
and probes (except 910.341: ø 6 mm), and
dovetail joint for lever-type dial test indicators
(908.957 without dovetail joint).

 With fine adjustment (except 908.962/964/957).
 Arm with mechanical central clamping device

(908.954/955: hydraulic).
 On/off switchable magnetic base with V‑groove,

except 908.964 and 910.341 (permanent
magnetic force), 908.961 (vacuum base)
and 908.975 (flexform base with locking
mechanism and permanent magnetic force).
 Various bases available.

908.962

910.341

908.954/955 908.964
908.956/957

908.975 908.961

Item No. Clamping Arm Description Dimensions Magnetic Thread Price
length 1/mm of base l x w x h/mm force 2/N of base EUR
35.50
908.953 mechanical 320 V‑groove 58 x 50 x 55 600 (S) M8 x 1.25 38.00 C06.304.EN.20250106
908.959 mechanical 340 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 43.00
908.960 mechanical 285 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 68.00
908.954 hydraulic 380 V‑groove 58 x 50 x 55 600 (S) M8 x 1.25 72.00
908.955 hydraulic 380 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 39.90
908.962 mechanical 150 V‑groove 36 x 30 x 35 400 (S) M5 x 0.8 26.90
908.964 mechanical cylinder ø 30 x 25 170 (P) M8 x 1.25 22.90
910.341 mechanical 65 cylinder ø 25 x 25 100 (P) M5 x 0.8 51.00
908.975 mechanical 60 flexform 75 x 46 x 55 400 (P) M8 x 1.25 48.00
908.961 mechanical 280 vacuum base ø 90 x 25 800 (S) M8 x 1.25 38.80
908.956 mechanical 280 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25 39.80
908.957 mechanical 360 V‑groove 60 x 50 x 55 M8 x 1.25
320

1 The outstretched length between base and clamping shaft.
2 S = switchable magnet; P = permanent magnetic force.
