DIAL INDICATOR STANDS Schut for Precision
Magnetic dial indicator stands
Solid dial indicator stands with on/off switchable magnetic base.
Clamping shaft: ø 6 and ø 8 mm.
Magnetic base with V‑groove.
Magnetic face at the back (except 855.707).
855.701 855.705 855.707
Item No. Dimensions Magnetic Column Arm Thread Price
855.701 base l x w x h/mm force/N mm mm of base EUR
855.705 58 x 50 x 55 M8 56.00
855.707 73 x 50 x 55 800 ø 12 x 176 ø 10 x 150 M8 131.00
117 x 50 x 55 1000 ø 20 x 178 ø 14 x 165 M20 228.00
1300 ø 20 x 365 ø 14 x 200
Magnetic dial indicator stands
Solid dial indicator stands with on/off
switchable magnetic base.
Clamping shaft: ø 6 and ø 8 mm.
Screw thread base: M8.
Magnetic base with V‑groove.
Magnetic face at the back.
855.706 855.710
Item No. Clamping Dimensions base Magnetic Arm length * Price EUR
l x w x h/mm force/N mm
855.706 hydraulic 73 x 50 x 55 1000 335 298.00 C06.204.EN.20240625
855.710 mechanical 58 x 50 x 55 800 335 144.00
* The outstretched length between base and clamping shaft.
