P. 277
Schut Geometrical Metrology DIAL INDICATOR STANDS
Fisso Strato Line and Strato µ‑Line dial indicator stands (continued)
Item No. Arm Thread Thread Price Item No. Price EUR
length/mm of head of base EUR
Separate arm without fine adjustment (Strato Line): With fine adjustment (Strato Line):
837.281 130 M6 M6 138.00 837.272 174.00
837.282 200 M6 M8 165.00 837.251 199.00
837.247 280 M6 M8 250.00 837.250 281.00
Separate arm without fine adjustment (Strato µ‑Line): With fine adjustment (µ‑Line):
839.875 130 M6 M6 160.00 839.878 3 382.00
839.876 200 M6 M8 174.00 839.879 3 396.00
839.877 287 M8 M8 266.00 839.880 3 484.00
837.912 330 M8 M8 300.00 837.232 3 517.00
Fisso Base Line dial indicator stands
Easy and handy dial indicator stands with high stability and accuracy.
Fine adjustment: with clamping shaft ø 8 mm
(for dial indicators and probes) and dovetail
joint (for lever-type dial test indicators).
Mechanical clamping device.
Dial indicator not included.
Complete stands (incl. base and fine adjustment)
Item No. Column Arm Base Magnetic Price
mm mm type * force/N EUR
837.224 ø 10 x 106 ø 8 x 75 S2 300 152.00 837.224 C06.315.EN.20250106
837.225 ø 12 x 156 ø 10 x 106 M 750 162.00
837.226 ø 14 x 184 ø 12 x 164 M 750 173.00
* For an extensive description of the base types see “Fisso dial indicator
stand accessories”.
© 2025, Schut Geometrische Meettechniek bv 277 Measuring instruments and systems 2023/2024
