MEASURING STANDS Schut for Precision
Measuring stands
Clamping shaft: ø 8 mm.
Transverse arm with fine adjustment.
Ground base with T‑groove.
Base with V‑groove
(only 909.376).
Item No. Column Arm Dimensions Price 906.219
mm mm base/mm EUR
906.219 ø 14 x 185 ø 12 x 245 220 x 60 x 35 57.00
909.376 ø 16 x 290 ø 16 x 310 260 x 60 x 50 148.00
Measuring stand with spindle adjustment
Measuring stand with clear graduation 0.02 mm on the spindle and a hand
wheel for easy adjustment of the height setting.
Clamping shaft: ø 8 mm.
Spindle thread pitch: 2 mm.
Column: ø 35 mm.
Transverse arm: ø 20 mm.
Granite measuring table: 260 x 150 x 50 mm,
measuring face: 250 x 150 mm,
flatness according DIN 876/00.
Total height: 410 mm.
Max. measuring height: 160 mm.
Delivery in a wooden box.
Item No. Description Price EUR C06.301.EN.20240625
907.789 Measuring stand 639.00
