DIAL INDICATOR STANDS Schut for Precision

Fisso dial indicator stand accessories

837.276

837.294

837.273

837.275

837.274

837.194 Item No. Type/ Magnetic Dimensions Thread Price
841.884 description force 1/N l x w x h/mm EUR

Magnetic bases: 46.00
54.00
837.294 S2 V‑groove 300 (S) 34 x 30 x 35 M6 82.00
V‑groove 600 (S) 40 x 40 x 40 M6 103.00
837.750 S3 V‑groove 800 (S) 60 x 50 x 55 M8 182.00
V‑groove 1000 (S) 75 x 50 x 55 M8 87.00
837.254 M flat 1500 (S) 120 x 60 x 55 M10 x 1.25 104.00
600 (P) 77 x 48 x 55 M8 27.60
837.255 SM anyform 600 (S) 91 x 52 x 55 M8 34.20
150 (P) M6
837.256 MM anyform 300 (P) ø 30 x 25 M8 153.00
cylinder ø 40 x 30 243.00
837.275 AM cylinder 77.00
77.00
837.227 837.291 AMO 84.00
84.00
837.280 837.276 TMS 43.00
837.803 49.00
837.257 TM
16.60
Other bases: V vacuum base ø 88 x 27 M8 16.60
837.273 G granite base 150 x 120 x 50 M8 24.30
837.274 – steel base 3x M6 24.30
837.194 – steel base ø 100 x 20 M8
837.195 – steel base ø 100 x 20 M6
837.196 – steel base ø 150 x 20 M8
837.292 – clamping base ø 150 x 20 2x M6
837.193 – clamping base 80 x 20 x 50 2x M8
837.227 80 x 30 x 50

Mounting plates made of aluminum, compatible with Fisso T-slot frame:

841.884 Mounting plate (slots 12 x 5 mm) 51.5 x 51.5 x 8 M6 2

841.885 Mounting plate (slots 12 x 5 mm) 51.5 x 51.5 x 10 M8 2

Adapters for internal thread/external thread: C06.316.EN.20250106
837.280 Adapter M6/M8 (hexagonal 13 x 25 mm, CrNi steel)
837.211 Adapter M8/M6 (hexagonal 13 x 25 mm, CrNi steel)
837.804 Adapter M8/M10 (ø 20 x 37 mm, steel)
837.803 Adapter M8/M12 (ø 20 x 40 mm, steel)

1 S = switchable magnet; P = permanent magnetic force.
2 Thread in the middle.
