Schut Geometrical Metrology DIAL INDICATOR STANDS

Fisso Classic Line dial indicator stands

These dial indicator stands are manufactured according to the classic principle with chrome plated
arm parts, joint together with the three hinge points by means of a central mechanic clamping device.
Because this is done with one on/off switch control, the stand can be positioned easily and precisely.
 Fine adjustment: with clamping shaft ø 8 mm (for dial

indicators and probes) and dovetail joint (for lever-type
dial test indicators).
 Dial indicator not included.
 Various bases, fine adjustments and other accessories
available; see “Fisso dial indicator stand accessories”.

837.287

839.870 837.290

Complete stands (incl. base and fine adjustment)

Item No. Arm Base Magnetic Price
length/mm type * force/N EUR

839.870 130 S2 300 205.00

837.262 200 M 800 255.00 837.264
837.290 200 AMO 600 301.00 837.245
837.264 200 TM 300 222.00
837.237 200
V – 307.00

837.245 288 M 800 295.00
837.265 288 SM 1000 312.00

837.287 450 SM 1000 505.00
837.266 450 MM 1500 581.00

837.246 630 MM 1500 784.00

* For an extensive description of the base types see “Fisso dial
indicator stand accessories”.

Item No. Arm Thread Thread Price Item No. Price
EUR EUR
length/mm of head of base
119.00
Separate arm without fine adjustment: 135.00 With fine adjustment:
839.871 130 M6 M6 172.00
837.283 197 M6 M8 365.00 839.872 160.00
837.284 288 M6 M8 568.00
837.285 453 M8 M8 837.267 176.00
837.286 635 M8 M10 x 1.25
837.252 213.00 C06.206.EN.20240625

837.268 406.00

837.253 609.00
