Schut Geometrical Metrology PROBE ACCESSORIES

Clamping bush 6 0.7 Inserts

12 Many inserts with thread
M2.5 are available. See the dial
ø10h8 indicator accessories section for
ø8H7 more information.
ø1.5
M4 Retraction levers
VKE VKD
Universal retraction levers, bottom or top
780.398 780.397 mounted, compatible with a wide range of
probes and dial indicators. You can find various
Item No. Description Price EUR models in the dial indicator accessories section.

780.398 Clamping bush VKE 9.60
780.397 Clamping screw VKD 3.60

Clamping bush

7 11 17.5
25.3

Item No. Description ø8H7 Retraction device DZ801
906.497 Clamping bush ø10h7
Pneumatic
Price EUR retraction device
26.10 for Magnescale and
TESA gauges, with
Probe holder 1 meter hose and air
tube connector.
Probe holder for for surfacemounting.
 Clamping shaft: ø 8 mm. Item No. Description Price EUR
 For attaching with M4 bolts. 344.465 Retraction device 162.00
 Material: anodized aluminum.

=30=

ø8 H7 ø4.5 THRU (2x) Clamp collar with dovetail

12 8=20= ø4.5 THRU For clamping TESA GT31 probes and e.g.
6=10= lever type dial indicators.
40  Fastening points:

ø 5.6 mm, ø 9.5 mm
and with dovetail.

Item No. Description M4x0.7 - 8 DEEP (2x) Item No. Description Price EUR C05.316.EN.20250106
993.054 Probe holder 780.208 Clamp collar 31.00
Price EUR
50.00
