Schut Geometrical Metrology PROBES

TESA analog probes

For years, TESA measuring probes have been used in both complex and simple measuring systems.
The top quality and absolute reliability of these probes is reason enough to use TESA probes again
and again. The most popular half-bridge probes, delivered calibrated, are noted in the following table.
For more information, also on LVDT probes, please refer to the comprehensive TESA catalog.

 Sensitivity: 73.75 mV/V/mm GT61
(GT61 and GT62: 29.5 mV/V/mm).

R 0.75 ø8 h6 R 0.75 ø8 h6 ø9.6 GT21

GT41 GT42 19 GT22
4 19 FMS100/130
4 34 13
47 36 FMS102/132

51
5.6 35.5

R1

GT43 ø8 h6

33 45°

5.6 18.4 9 20
29.5

8
8
M6 M6

R1 5 15 30 15 5 5 15 30 15 5
ø8 h6 70 38 70

GT44 Item No. Type Measuring Dimensions/mm Price
R 1.5 ø8 h6 range/mm A B C EUR

AB 780.654 GT21 ± 1 20.5 61.5 92 369.00
C 780.687 GT21HP ± 0.2 20.5 61.5 92 795.00
780.662 GT22 ± 1 20.5 47 81.5 388.00
GT21(HP) / GT61 780.673 GT22HP ± 0.2 20.5 47 81.5 814.00
780.692 GT61 ± 5 29.5 81 120 587.00
R 1.5 ø8 h6 ø9.6 780.693 GT62 ± 5 29.5 67.2 110.7 601.00
781.945 GT622 ± 5 29.5 67.2 110.7 666.00
780.667 GT41 ± 0.3 – – – 588.00
780.668 GT42 ± 0.3 – – – 615.00
780.686 GT43 ± 1 – – – 523.00
780.670 GT44 ± 1 – – – 530.00
780.652 GT31 ± 0.3 – – – 939.00
780.672 FMS100 ± 2 – – – 836.00
780.679 FMS102 ± 2 – – – 944.00
781.946 FMS130 ± 2.9 – – – 957.00
781.947 FMS132 ± 2.9 – – – 1,055.00
AB 17 19
C
C05.347.EN.20240625
GT22(2)(HP) / GT62(2)

782.328 Set (10 pcs.) GT21 3,305.00
782.329 Set (10 pcs.) GT22 3,423.00

ø2 90 Options: 355.00
40 50 783.225 DIN/USB adapter for analog probes 355.00

GT31 with measuring range ± 2 mm
783.284 DIN/USB adapter for analog probes

with measuring range ± 5 mm
