Schut Geometrical Metrology ELECTRONIC INDICATORS
TESA TWIN-T10 display unit
Portable electronic display unit for TESA inductive probe with a very long battery operating time
(up to 400 hours). The function keys can be operated separately and the soft rubber casing makes the
TWIN-T10 very robust and easy to hold.
The large display with a high contrast and the design of the detailed segmentation of the analog
scale (5-fold zoom function) makes it possible to visualize very precise movements and slight
variations in form or to detect the reversal point. The TWIN-T10 features max, min, max-min and
tolerance functions. The TWIN-T10 is very suitable for the evaluation of straightness, run-out, form
or geometry during fine adjustment, alignment or fitting of mechanical parts.
The probe is automatically recognized. In the display 7 different measuring ranges can be set and
an automatic setting. With the calibration function it is possible to tune the TWIN-T10 in combination
with the connected probe, or with a dummy probe. With the TLC-USB cable or the TLC-BLE
transmitter (for wireless data transfer) bidirectional communication is possible with the PC. Digimatic
data output is also possible with the TLC-Digimatic cable.
7 measuring ranges: ± 5 mm, ± 2 mm, Protection: IP63 (except connections for
± 500 µm, ± 200 µm, ± 50 µm, ± 20 µm, probe and switch).
± 5 µm and an automatic setting. Delivery with 4 batteries type AA.
Digital and digital-analog read-out.
Resolution: 1 µm or 0.1 µm.
1 probe input.
Measure with or without tolerance limits;
Go/NoGo indication on display.
Offset function: within 200 µm directly set to
zero.
Memory for min., max. and max-min. value.
mm/inch conversion.
Frequency limit: 10 Hz (relative to the input
signal).
Response time: ≤ 100 ms.
Calibration with gauge blocks or dummy probe.
Bidirectional data transfer.
RS232C data output.
On/off switch.
Automatic switch-off. Also available in
Key lock function. 783.468 µ-FINDER set 783.548.
Reversible measuring Item No. Description Price EUR
direction.
Operating temperature:
10 to 40°C. 783.468 TESA TWIN-T10 1,467.00
Autonomy:
Options: 0.70
up to 400 hours. 495.111 Spare battery type AA (4 needed) 939.00
Dimensions: 780.652 GT31 probe 113.00
780.951 Hand switch 1.8 m 344.00
170 x 100 x 38 mm. 780.952 Foot switch 1.8 m
783.301 TESA Link Connector USB 128.00
783.302 TESA Link Connector Digimatic 262.00
783.555 TESA Link Connector Bluetooth 52.00
783.037 DATA-Direct software for data aquisition 443.00
783.038 STAT-Express for statistical analysis 1,072.00
779.982 Back support with centered lug 59.00 C05.327.EN.20240625
779.981 Back support with off-centered lug 98.00
© 2024, Schut Geometrische Meettechniek bv 259 Measuring instruments and systems 2023/2024
