ELECTRONIC INDICATORS Schut for Precision
TESA TWIN-T20 display-unit
The TWIN-T20 is an interface which allows the user to read two instruments at the same time.
Both digital and analog probes, calipers, dial indicators and many more instruments can be connected.
The probes are automatically recognized by the interface, ensuring a reliable measurement. The
7" touchscreen allows the user to display up to two different sensors at the same time, and change
all the settings intuitively. The TWIN-T20 is very suitable for use in a laboratory or a production
environment. Measurement results can be saved on a PC by means of a USB stick, RS232/USB cable
or the TLC-BLE Bluetooth transmitter. TESA provides the software “Data-Viewer” which can be
downloaded free of charge.
2 probe inputs for half bridge probes. Switching of polarity, choice between internal
2 USB-A inputs for Tesa measuring and external measurements.
instruments (except USB probes). Storage for 2 measurement programs
2 USB-A inputs for peripherals such as possible.
keyboard, foot switch, memory stick, QR / Zero point can be set per channel.
barcode reader. Holder to be mounted on DIN rail.
1 USB-B output for HID keyboard. Dimensions: 190 x 112 x 119 mm.
Connection for TESA TLC Bluetooth Degree of protection: IP65 (front).
Transmitter. Delivery with AC adapter, calibration
RS232/TESA BUS output.
Display of 2 probes/measuring instruments certificate and quick start manual.
simultaneously.
4 display options.
8 measuring ranges: ± 5000 µm - ± 5 µm
and an automatic setting.
Resolution: 0.1 µm / 0.00001 in.
Static and dynamic measurements. 4300
samples per second.
Storage of min., max., max-min value,
average.
Addition function: ± A ± B.
Tolerance indication, go, no-go or rework.
Item No. Description Price EUR C05.334.EN.20250106
783.637 Tesatronic TWIN-T20 1,667.00
Options:
780.952 Foot switch 1.8 m 344.00
783.639 Touch pen 140.00
783.301 TESA Link Connector USB 128.00
783.302 TESA Link Connector Digimatic 262.00
783.555 TESA Link Connector Bluetooth 52.00
783.027 Cable USB-Opto RS232 duplex (2 m) 294.00
782.006 RS232C cable 2 m 24.00
