DIAL TEST INDICATOR ACCESSORIES Schut for Precision

TESA dial test indicator accessories Price EUR
31.00
Item No. Description 17.50
783.698 12 Knurled fixing shaft ø 4 x 15 mm 105.00
782.867 13 Knurled fixing shaft ø 8 x 15 mm 59.00
780.171  Fixing shaft ø 4 x 12 mm 64.00
780.172  Fixing shaft ø 8 x 12 mm 80.00
780.173  Cylindrical fixing shaft ø 8 x 80 mm, clamping shaft ø 5.6 mm 140.00
783.697 14 Swivelling fixing shaft ø 4 x 64 mm 31.00
783.534 15 Swivelling fixing shaft ø 8 x 64 mm 234.00
780.175  Swivelling holder ø 8 x 25 mm 34.00
780.176  Swivelling holder ø 8 x 90 mm 53.00
780.177  Angle holder ø 8 x 25 mm, clamping shaft ø 8 mm
780.178  Centering support ø 8 x 25 mm, clamping shaft ø 4 mm
780.208  Double fixing clamp ø 5.6 / ø 9.5 mm, with dovetail clamp
782.787  Swivelling holder ø 8 x 125 mm, with fine adjustment
782.590  Fixing shaft ø 6 x 12 mm
855.600 11 Fixing shaft 9 x 11 x 106 mm complete with dovetail clamp and

clamping shaft ø 6 mm

12 13 14 15

Measuring inserts for lever-type dial test indicators

Inserts for TESA lever-type dial test indicators, with tungsten carbide * tip and thread M1.4

780.199 780.206 Item No. Length/mm ø/mm Price EUR
780.199 12.53 1 13.00
780.200 780.200 12.53 2 14.50 C05.229.EN.20240625
780.201 12.53 3 16.00
780.201 780.202 36.53 1 34.00
780.203 36.53 2 32.00
* Also available with ruby tip. 780.204 36.53 3 34.00
780.206 Key
3.20
