Schut Geometrical Metrology DIAL TEST INDICATORS

TESA lever-type dial test indicators

 Measuring range: up to 2 mm.  Insert thread: M1.4.
 Graduation: 0.02, 0.01, 0.002 or 0.001 mm.  DIN 2270.
 With dovetail joint.  Delivery in a plastic case with a clamping
 Rotatable dial.
 Tungsten carbide (Tesatast) or ruby (Rubytast) stem (780.172).

stylus tip, ø 2 mm.

780.143 - 780.149 - 780.152 - 781.466 -
780.148 780.151 780.154 781.467

Item No. Measuring Accuracy Graduation Dial Scale Insert Price
range/mm mm mm ø/mm numbering length/mm EUR
159.00
Tesatast, horizontal: 0.010 0.01 28 0 - 0.4 - 0 12.53 169.00
780.143 0.8 0.010 0.01 38 0 - 0.4 - 0 12.53 180.00
780.144 0.8 0.010 0.01 28 0 - 0.25 - 0 36.53 196.00
780.145 0.5 0.010 0.01 38 0 - 0.25 - 0 36.53 180.00
780.146 0.5 0.002 0.002 28 0 - 100 - 0 12.53 198.00
780.147 0.2 0.002 0.002 38 0 - 100 - 0 12.53 204.00
780.148 0.2 0.002 0.001 38 0 - 100 - 0 12.53 286.00
780.820 0.2 307.00
321.00
Tesatast, lateral: 0.010 0.01 28 0 - 0.4 - 0 12.53 304.00
780.149 0.8 0.027 0.02 38 0 - 1.0 - 0 36.53 425.00
780.150 2.0 0.002 0.002 28 0 - 100 - 0 12.53 380.00
780.151 0.2 178.00
212.00
Tesatast, perpendicular: 0.010 0.01 28 0 - 0.4 - 0 12.53
780.152 0.8 0.010 0.01 28 0 - 0.25 - 0 36.53
780.153 0.5 0.002 0.002 38 0 - 100 - 0 12.53
780.154 0.2

Rubytast, horizontal: 0.010 0.01 28 0 - 0.4 - 0 12.53 C05.227.EN.20250106
781.466 0.8 0.0027 0.002 38 0 - 100 - 0 12.53
781.467 0.2
