Schut Geometrical Metrology DIAL TEST AND SAW TOOTH INDICATORS

Käfer lever-type dial test indicators

Käfer lever-type dial test indicators have a very high accuracy because of the ruby ball bearing.
The direction of the rotation is independent of the measuring direction. Equipped with three dovetail
mountings. Are standard delivered with a clamping stem ø 8 mm.
 Measuring range: up to 0.8 mm.
 Graduation: 0.01 or 0.002 mm.
 With dovetail joint and clamping stem ø 8 mm.
 Rotatable dial.
 Tungsten carbide stylus tip: ø 2 mm.
 Insert thread: M1.6

(optional inserts on request).
 240° adjustable measuring insert.
 Ruby ball bearing.
 DIN 2270.
 Delivery in a plastic case with a key.
 Various different models available.

852.361 852.362 852.363

Item No. Measuring Graduation Dial Scale Insert Price
range/mm mm ø/mm numbering length/mm EUR

852.361 0.8 0.01 32 0 - 40 - 0 12 88.00
852.362 0.5 0.01 32 0 - 25 - 0 35 123.00
852.363 0.2 0.002 40 0 - 100 - 0 12 110.00

Käfer saw tooth indicator

By placing the indicator on the saw blade you can easily measure the flatness of the blade, enabling
you to saw very precisely. With the indicator you can also measure the height difference between
the saw blade and the tooth. This principal of
differential measuring of thickness or heights
is not only suited for saw blades, but has many
other applications.

Because the indicator has a two‑sided
read‑out, it is usable for left- as well as
right‑handers.
 Measuring range: 0 - 2 mm.
 Graduation: 0.05 mm.
 Rotatable dial.
 Adjustable tolerance marker.

Item No. Description Price EUR C05.228.EN.20250106
852.364 Saw tooth indicator 77.00

© 2025, Schut Geometrische Meettechniek bv 251 Measuring instruments and systems 2023/2024
