DIAL TEST INDICATORS Schut for Precision

Mitutoyo lever-type dial test indicators 0.001 and 0.002 mm

These dial test indicators are able to measure in both directions without having to switch direction.

 Measuring range: up to 0.6 mm. Inserts
 Graduation: 513.401: 0.001 mm,
Item No. Ball Price
513.465/406/425/475: 0.002 mm. ø/mm EUR
 With dovetail joint and clamping stem ø 8 mm.
 Dial diameter: 513.465: ø 29 mm, For 513.401: 21.00
103.010 1 2 30.00
513.401/406/425/475: ø 40 mm. 290.547 3 0.5 24.00
 Rotatable dial. 290.548 3 0.7 16.00
 Tungsten carbide stylus tip: ø 2 mm, (except 103.017 1 1 33.00
210.209 2 2 16.00
513.475, ruby stylus tip: ø 2 mm). 103.018 1 3
 Insert thread: M1.7.
 Jewel beared clockwork. For 513.465/406/425/475:
 Antimagnetic.
 Delivery in a plastic case with a manufacturer 103.011 1 2 21.00

measuring report and a clamping stem. 131.314 1 1 10.00
 Various different models available.
131.315 1 3 12.00

210.068 2 2 25.00

513.401 1 Tungsten carbide.
2 Ruby.
3 Steel.

Item No. Measuring Accuracy Measuring Scale Insert Insert length Price EUR
range/mm mm force/N numbering (L1/L2)/mm
513.401 103.010 187.00
513.465 0.14 0.003 ≤ 0.3 0 - 70 - 0 103.011 14.7/11.2 178.00 L1 L2
513.406 0.2 0.003 ≤ 0.3 0 - 100 - 0 103.011 18.7/15.2 137.00
513.425 0.2 0.003 ≤ 0.3 0 - 100 - 0 103.011 18.7/15.2 188.00
513.475 0.6 0.007 ≤ 0.4 0 - 100 - 0 210.068 18.7/15.2 164.00
0.2 0.003 ≤ 0.3 0 - 100 - 0 18.7/15.2

Mitutoyo lever-type dial test indicator sets 513.404

The sets 513.404/408 consist of: 513.404 513.908
– lever-type dial test indicator,
– insert with tungsten carbide tip ø 1 mm, ø 2 mm and ø 3 mm, Accuracy/mm Price EUR
– union nut, clamping stem ø 4 mm and ø 8 mm,
– universal rotatable holder, 0.008 143.00
– clamping stem for height gauge (9 x 9 x 100 mm), 0.003 175.00
– manufacturer measuring report and plastic case. 0.008 167.00
Set 513.908 consists of:
– lever-type dial test indicator,
– insert with tungsten carbide tip ø 2 mm,
– small magnetic dial indicator stand (150 N

magnetic force, holder ø 6 mm and ø 8 mm),
– shaft with serrated clamping ring,
– manufacturer measuring report and plastic case.

Item No. Description

513.404 Lever-type dial test indicator 0.8 mm (513.403) with several accessories C05.328.EN.20250106
513.408 Lever-type dial test indicator 0.2 mm (513.406) with several accessories
513.908 Lever-type dial test indicator 0.8 mm (513.403)
with small magnetic dial indicator stand

© 2025, Schut Geometrische Meettechniek bv 248 Measuring instruments and systems 2023/2024
