Schut Geometrical Metrology DIAL INDICATOR ACCESSORIES

Clamping bush Clamping bush 17.5

12 6 0.7

ø10h8
ø8H7
ø1.5
M4

11
7
25.3
VKE VKD

780.398 780.397 ø8H7
ø10h7
Item No. Description Price EUR
Price EUR
780.398 Clamping bush VKE 9.60 Item No. Description 26.10
780.397 Clamping screw VKD 3.60 906.497 Clamping bush

Swivel-type probe Angle probe

Swivel-type probe for dial indicators with M2.5 Angle probe used for the transmission of the
thread. The probe can be oriented over 180°. plunger movements up to 10 mm. Suited for dial
Equipped with a steel ball probe ø 3 mm. indicators with a 0.01 mm graduation. Delivery
incl. flat insert ø 5 mm.
37  Probe measuring range:
26
10 mm.
ø3  Clamping shaft:

ø 8 mm.

Item No. Description Price EUR
782.440 Angle probe 279.00

Item No. Description Price EUR Probe holder
900.391 Swivel-type probe 33.00

Angle probe and special probe Probe holder for for surfacemounting.

Probes e.g. for checks and alignments of  Clamping shaft: ø 8 mm.
bores on lathes.  For attaching with M4 bolts.
 Probe measuring range: 10 mm.  Material: anodized aluminum.
 Measuring depth: 30 mm (856.149)
=30=
or 60 mm (856.150).
 Clamping stem: ø 8 mm. ø8 H7 ø4.5 THRU (2x)
 Clamping shaft: ø 8 mm.
6
12 8 40

=20= ø4.5 THRU
=10=

856.149 856.150

Item No. Description Price EUR Item No. Description M4x0.7 - 8 DEEP (2x)
113.00 993.054 Probe holder
856.149 Angle probe 106.00 Price EUR C05.309.EN.20250106
856.150 Special probe 50.00
