INSERTS Schut for Precision
Extensions for inserts
Steel extensions for inserts with thread M2.5.
Item No. Length mm Price EUR M2.5-6g Item No. Length mm Price EUR
5.40 5 5.50
Extensions with A = ø 4 mm: 5.40 Extensions with A = ø 5 mm: 5.50
852.446 10 5.40 852.465 10 5.50
852.447 15 5.40 852.466 15 5.50
852.448 20 5.40 852.467 20 5.50
852.449 25 5.40 852.468 25 5.50
852.450 30 5.40 852.469 30 5.50
852.451 35 5.40 852.470 35 5.50
852.452 40 5.40 852.471 40 5.50
852.453 45 5.40 852.472 45 5.50
852.454 50 5.40 852.473 50 5.50
852.455 55 5.40 L 852.474 55 5.50
5.40 5.50
852.456 60 5.40 852.475 60 5.50
852.457 65 5.40 852.476 65 5.50
852.458 70 5.40 852.477 70 5.50
852.459 75 5.40 852.478 75 5.50
852.460 80 5.40 852.479 80 5.50
852.461 85 5.40 M2.5- 6H 852.480 85 5.50
852.462 90 852.481 90
852.463 95 852.482 95
852.464 100 A 852.483 100
Adapters for inserts
Adapter for attaching other inserts to dial indicators and probes with an interchangeable insert with
thread M2.5.
Item No. External/internal thread Price EUR ø4
M2
960.276 M2.5/M2 13.40 M2.55
Käfer long angular heads for dial indicators
Clamping shaft: ø 8 mm.
Extensions stem: ø 8 mm.
Thread for inserts and extensions: M2.5.
Max. probe travel: 4 mm.
One extension and extra insert are needed for
the angular head to function.
Please see the dial indicator accessories
section for these inserts.
Item No. Description Price EUR
851.019 851.020 851.021 851.024 Long angular heads: C05.336.EN.20240625
851.019 Long angular head 90°
851.020 Long angular head 45°
851.021 Long angular head 0°
Extensions:
851.022 Extension 15 mm
851.023 Extension 25 mm
851.024 Extension 50 mm
851.025 Extension 75 mm
851.026 Extension 100 mm
