P. 235
Schut Geometrical Metrology DIAL INDICATORS
Precision dial indicator
Highly accurate dial indicator for measurements from a fixed reference point. Very suitable for
internal measuring instruments and dial indicator stands for example.
Measuring range: 0.1 mm.
Graduation: 0.001 mm.
Measuring force: < 2 N.
Clamping stem: ø 8 mm.
Travel: 3 mm.
Adjustable tolerance markers.
Fine adjustment.
Delivery in a plastic case with a manufacturer
measuring report.
Item No. Measuring Dial Price
range/mm ø/mm EUR
182.00
907.939 0.1 63.5
Precision dial indicators
Measuring range: 0.06 mm.
Graduation: 0.0005 mm or 0.001 mm.
Measuring force: approx. 1 N.
Clamping stem: ø 28 mm.
Shockproof.
Fine adjustment.
Delivery with an inspection report.
For dial indicator stands see dial indicator
stands elsewhere in this catalog.
Item No. Measuring Resolution Scale Price
range/mm mm numbering EUR
15 - 0 - 15 139.00
906.332 0.03 0.0005 30 - 0 - 30 113.00 906.333 C05.339.EN.20250106
906.333 0.06 0.001
© 2025, Schut Geometrische Meettechniek bv 235 Measuring instruments and systems 2023/2024
