TESA dial indicators
TESA precision dial indicators with a high accuracy and a special construction guaranteeing a very
long life.
Measuring range: 0 - 50 mm. Flat back, except 782.296.
Graduation: 0.1 - 0.001 mm. Delivery with a declaration of conformity.
Clamping stem: ø 8 mm.
Rotatable dial with adjustable tolerance
markers.
783.632 782.724 783.644 783.494
783.643
Item No. Measuring Accuracy Dial Scale Shockproof Price
range/mm mm ø/mm numbering EUR
Graduation 0.1 mm: 40 0 - 10 no 115.00
783.632 0 - 10 0.055 58 0 - 10 no 88.00
782.801 0 - 10 0.055
783.494 0 - 30 0.055 58 0 - 10 no 107.00
Graduation 0.01 mm: 0.017 28 0 - 50 no 163.00
783.643 0 - 3.5 0.012 40 0 - 50 yes 115.00
782.723 0 - 5 0.015 58 0 - 100 yes 75.00
782.724 0 - 10
783.538 0 - 30 0.020 58 0 - 100 no 196.00 783.538
783.633 0 - 50 0.025 58 0 - 100 no 263.00 782.296
Graduation 0.01 mm, protection IP67: 0 - 50 yes 221.00
783.644 0 - 5 0.012 44.5 0 - 100 yes 221.00
783.648 0 - 10 0.015 61.5
Graduation 0.002 mm: 44.5 0 - 20 yes 263.00
783.645 0 - 3 0.007 61.5 0 - 20 yes 256.00
783.649 0 - 5 0.010
Graduation 0.002 mm, protection IP67: yes 342.00
783.646 0 - 3 0.007 44.5 0 - 20
Graduation 0.001 mm: 0.005 44.5 0 - 10 yes 291.00
783.647 0 - 1 0.005 61.5 0 - 10 yes 274.00
783.650 0 - 1 0.010 61.5 0 - 20 yes 298.00
783.651 0 - 5
Clamping stem on back side: 0 - 50 no 199.00 C05.333.EN.20240625
