DIAL INDICATORS Schut for Precision

TESA dial indicators

TESA precision dial indicators with a high accuracy and a special construction guaranteeing a very
long life.

 Measuring range: 0 - 10 mm.  Fine adjustment (only 781.682).
 Graduation: 0.01 - 0.001 mm.  Flat back.
 Clamping stem: ø 8 mm.  DIN 878 (except 781.682 and 783.221).
 Measuring force: approx. 1 N (only 781.682).  DIN 879 (only 781.682).
 Rotatable dial (except 781.682).
 Adjustable tolerance markers.

779.925 782.417 783.221 781.682

Item No. Measuring Accuracy Dial Scale Shock- Graduation Price
range/mm mm ø/mm numbering proof mm EUR

781.681 0 - 5 0.014 40 0 - 50 no 0.01 197.00
58 0 - 100
781.693 0 - 1 0.005 58 0 - 200 yes 0.001 325.00
781.695 0 - 5 0.005 58 0 - 100 yes 0.001 322.00
781.691 0 - 10 0.017 58 0 - 100 no 0.01 200.00
781.686 0 - 10 0.017 40 0 - 100 yes 0.01 233.00
40 0 - 100
779.913 1 0 - 1 0.005 40 0 - 50 yes 0.001 336.00
781.685 1 0 - 1 0.005 40 0 - 50 yes 0.001 242.00
781.683 1 0 - 5 0.014 40 20 - 0 - 20 no 0.01 115.00
779.925 1 0 - 5 0.014 40 0 - 50 yes 0.01 270.00
58 50 - 0 - 50
783.253 0 - 0.4 0.014 58 0 - 100 no 0.01 118.00
782.417 0 - 5 0.014 62 50 - 0 - 50 no 0.01 197.00

783.221 0 - 1 0.009 yes 0.01 288.00
782.799 0 - 10 0.017 no 0.01 200.00

781.682 1 0 - 0.1 0.0012 yes 0.001 238.00 C05.221.EN.20240625

1 Protection: IP54.
