P. 233
Schut Geometrical Metrology DIAL INDICATORS
Käfer dial indicators 0.01 mm
These recently developed Käfer dial indicators are very stable and have a very good price-performance
ratio. Also available in a shockproof design, where blows against the plunger can not damage the
mechanics.
Measuring range: 0 - 10 mm. Clamping stem and measuring pin out of
Graduation: 0.01 mm. hardened stainless steel.
Clamping stem: ø 8 mm.
Dial diameter: 40 mm (851.700: 58 mm). DIN 878.
Scale numbering: 0 - 50 (852.291: 0 - 100), Delivery in a plastic case.
(851.700: 0 - 50 - 0).
Adjustable tolerance markers.
Flat back.
Item No. Measuring Graduation Price
range/mm mm EUR
852.350 0 - 3 0.01 49.00
852.352 0 - 5 0.01 62.00
Shockproof design: 78.00 852.353
851.700 0 - 0.8 0.01 61.00
852.351 0 - 3 0.01 78.00
852.353 0 - 5 0.01 88.00
852.291 0 - 10 0.01
Käfer dial indicators 0.01 mm
These dial indicators have an almost constant measuring force of 1 N over the total measuring
range. This is achieved through a built-in lever construction. The shockproof design protects the
mechanics against harsh blows and reduces the possibility of damage. The shockproof design has an
unbreakable cover glass.
Measuring range: 0 - 10 mm.
Graduation: 0.01 mm.
Measuring force: approx. 1 N.
Clamping stem: ø 8 mm.
Dial diameter: 58 mm.
Scale numbering: 0 - 100.
Adjustable tolerance markers.
Flat back.
DIN 878.
Delivery in a plastic case.
Item No. Measuring Graduation Price 852.355
range/mm mm EUR Measuring instruments and systems 2023/2024
852.354 0 - 10 0.01 47.00
Shockproof design: 50.00 C05.223.EN.20240625
852.355 0 - 10 0.01
© 2024, Schut Geometrische Meettechniek bv 233
