DIAL INDICATORS Schut for Precision
Mitutoyo dial indicators 0.01 and 0.001 mm
Dial indicators from Mitutoyo with a very favourable price-performance ratio. In our catalog
we only represent a small part of the Mitutoyo program, but we can supply all Mitutoyo products.
Graduation: 0.01 or 0.001 mm.
Clamping stem: ø 8 mm.
Dial diameter: 55.6 mm.
Rotatable dial.
Various models available.
Locking screw and adjustable tolerance
markers optionally available.
Graduation 0.01 mm 204.600
Measuring range: 0 - 10 mm.
Accuracy: ± 0.013 mm.
Max. hysteresis: 0.003 mm.
Measuring force: 1.4 N.
1 pointer revolution = 1 mm.
Scale numbering: 0 - 100 (100 - 0).
Flat back or back with lug 1.
Item No. Measuring Graduation Price
range/mm mm EUR
204.600 1 0 - 10 0.01 49.00
204.601 0 - 10 0.01 48.00
204.602 2 0 - 10 0.01 141.00
1 Back with lug.
2 Splashproof model; measuring force 2.5 N.
211.010
Graduation 0.001 mm 210.912
Measuring range: 0 - 1 mm.
Accuracy: ± 0.005 mm. 211.148 + 211.195
Max. hysteresis: 0.002 mm.
Flat back. (Back with lug available
on request.)
Conforms to factory standard.
Item No. Measuring Graduation 1 pointer Scale Measuring Price
range/mm mm revolution numbering force/N EUR
0 - 100 - 0 106.00
210.912 0 - 1 0.001 0.2 mm 0 - 100 (100 - 0) 1.5 137.00
211.010 0 - 1 0.001 0.1 mm 1.5
1.70
Options: 0.60 C05.273.EN.20240625
211.148 Locking screw for 2 series dial indicators
211.195 Tolerance markers for 2 series dial indicators
