DIAL INDICATORS Schut for Precision

Käfer dial indicators 0.01 mm

These Käfer dial indicators combine a large measuring range with a high accuracy.
The clear dials ensure an easy read-out. Thanks to the special construction, these dial
indicators have an almost constant measuring force on the whole measuring range.

 Measuring range: 0 - 100 mm.  Conforms to factory standard.
 Graduation: 0.01 mm.
 Measuring force: approx. 1 N 852.357

(852.290 approx. 1.5 N, 852.289 approx. 1.2 N).
 Clamping stem: ø 8 mm

(except 852.289: ø 10 mm).
 Dial diameter: 58 mm.
 Rotatable dial.
 Adjustable tolerance markers.
 Flat back.
 Clamping stem and measuring pin out of

hardened stainless steel.

Item No. Measuring Accuracy Scale Price
range/mm mm numbering EUR
852.356

852.356 0 - 30 ± 0.02 0 - 100 113.00
852.357 0 - 50 ± 0.025 0 - 100 162.00
852.290 0 - 80 ± 0.030 0 - 100 333.00
852.289 0 - 100 ± 0.050 0 - 100 424.00

Käfer Feinika dial indicators 0.001 mm

The Käfer Feinika dial indicators have a special construction without gear wheels, comparable to
the precision dial indicators. A special lever construction enlarges the measuring range up to 1 mm.
This lever construction gives the Feinika a very low hysteresis of maximal 1.5 µm, making it very
suitable for very accurate comparative measurements where a large measuring range is necessary. Just
like the precision dial indicators the Feinika has a resolution of 0.001 mm.

 Measuring range: 0 - 1 mm.
 Graduation: 0.001 mm.
 Hysteresis: ≤ 0.0015 mm.
 Clamping stem: ø 8 mm.
 Shockproof.
 Adjustable tolerance markers.
 Conforms to factory standard.
 Delivery in a plastic case.

852.359 Item No. Measuring Accuracy Dial Scale Price
range/mm mm ø/mm numbering EUR

852.358 0 - 1 ± 0.004 40 0 - 100 206.00 C05.224.EN.20240625
852.359 0 - 1 ± 0.004 58 0 - 100 206.00
