DIAL TEST INDICATORS Schut for Precision

Interapid lever-type dial test indicators The sets consist of:
– dial test indicator,
 Measuring range: up to 1.6 mm. – rectangular holder with
 Graduation: 0.01 or 0.002 mm.
 Angle between insert and workpiece for true reading: 12°. clamp,
 With dovetail joint and clamping stem ø 4 mm. – reducing sleeve,
 Rotatable dial. – swivel holder,
 Hardened steel stylus tip: ø 2 mm. – key,
 Insert thread: M1.7 (optional inserts on request). – case.
 Delivery in a plastic case.

781.520

781.526

781.524

Item No. Measuring Accuracy Graduation Dial Scale Insert Price Item No. Price
range/mm mm mm ø/mm EUR
numbering length/mm EUR In a set:
781.526 456.00
Horizontal: 1.6 0.023 0.01 37.5 0 - 40 - 0 16.5 336.00 781.527 452.00
781.520 1.6 0.023 0.01 30 0 - 40 - 0 16.5 334.00 781.528 520.00
781.521 0.4 0.010 0.002 37.5 0 - 10 - 0 15.2 381.00 781.529 528.00
781.522 0.4 0.010 0.002 30 0 - 10 - 0 15.2 381.00
781.523

Perpendicular: 0.023 0.01 37.5 0 - 40 - 0 16.5 353.00 C05.226.EN.20250106
781.524 1.6 0.023 0.01 30 0 - 40 - 0 16.5 353.00
781.525 1.6
