Schut Geometrical Metrology INTERNAL MEASURING INSTRUMENTS

Krœplin internal measuring instruments Intertest

Measuring instruments for accurate and reliable measurements of internal dimensions.

 Measuring range: 2.5 - 430 mm.  Dust and drip proof.
 Graduation: 0.005, 0.01, 0.05, 0.1 or 0.2 mm.  Damped movement of the measuring arm.
 Very fine tolerances on the various parts.  Adjustable tolerance markers.
 Impact and shock-resistant housing.  Protection: IP65.
 Delivery with a manufacturer measuring report.

854.922 854.924

Item No. Type Meas. Gradu- Accu- Repeat- Price Types of inserts
range ation racy ability EUR
mm mm mm mm 854.025 / 026

854.922 H102 2.5 - 12.5 0.005 ± 0.015 0.005 429.40
854.923 H105 5 - 15 0.005 ± 0.015 0.005 429.40

854.924 H210 10 - 30 0.01 ± 0.03 0.01 429.40
854.925 H220 20 - 40 0.01 ± 0.03 0.01 429.40
854.926 H230 30 - 50 0.01 ± 0.03 0.01 429.40
854.927 H240 40 - 60 0.01 ± 0.03 0.01 429.40
854.928 H250 50 - 70 0.01 ± 0.03 0.01 429.40
854.929 H260 60 - 80 0.01 ± 0.03 0.01 429.40
854.930 H270 70 - 90 0.01 ± 0.03 0.01 429.40
854.931 H280 80 - 100 0.01 ± 0.03 0.01 429.40

854.019 H415 15 - 65 0.05 ± 0.05 0.025 494.20
854.020 H440 40 - 90 0.05 ± 0.05 0.025 494.20
854.021 H470 70 - 120 0.05 ± 0.05 0.025 569.30
854.022 H4100 100 - 150 0.05 ± 0.05 0.025 569.30
854.023 * H4130 130 - 180 0.05 ± 0.05 0.025 569.30
854.024 * H4150 150 - 200 0.05 ± 0.05 0.025 610.60

854.227 H850 50 - 150 0.1 ± 0.15 0.1 932.40
854.228 H870 70 - 170 0.1 ± 0.15 0.1 932.40
854.361 * H1290 90 - 190 0.1 ± 0.3 0.1 1,151.60
854.360 * H12150 150 - 250 0.1 ± 0.3 0.1 1,151.60
854.362 * H16200 200 - 400 0.2 ± 0.4 0.2 1,235.80

854.932 * H2M50 50 - 100 0.01 ± 0.03 0.015 655.50
854.933 * H2M90 90 - 140 0.01 ± 0.03 0.015 655.50
854.957 * H2M130 130 - 180 0.01 ± 0.03 0.015 703.30

854.025 * H4M180 180 - 310 0.05 ± 0.1 0.05 754.50
854.026 * H4M300 300 - 430 0.05 ± 0.15 0.05 809.90

Options: 31.90
859.233 Wooden case type 1732-45 47.10
854.098 Wooden case type 1732-51
854.099 Wooden case type 1732-53

* Delivery incl. wooden case.

For specifications refer to the 859.233 854.932 / 933 / 957 C04.238.EN.20250106
Krœplin internal measuring
instruments overview.
